November 29, 2025 0 comments

Unleashing the power of 3D in Draftsight Enterprise Plus

Introduction:

DraftSight has long been recognized for its precision 2D drafting capabilities. But with the evolution of design workflows, engineers and designers now need to visualize and model their ideas in three dimensions. The 3D Workspace in DraftSight Enterprise Plus brings exactly that — powerful 3D modeling tools integrated into a familiar drafting environment.

Unleashing the power of 3D in Draftsight Enterprise Plus Step-by-Step Guide:

Step 1: Make a 2d sketch

  1. Create a circle using the “cir” command and press enter.
  2. Then select (0,0) as centre point and the enter 50 as radius.
  3. Then press enter , the circle is generated in the graphical area.
Unleashing the power of 3D in Draftsight Enterprise Plus

Step 2: Switch the workspace

The workspace in DraftSight provides a flexible environment that adapts to your design needs, offering predefined layouts such as 2D Drafting and 3D Modeling. Users can easily switch between these workspaces depending on their tasks or customize their own by arranging toolbars, ribbons, and palettes for maximum efficiency. Customized workspaces can be saved, transferred, and reused across systems, ensuring consistency and productivity for teams. This flexibility allows designers to maintain a clean, task-specific interface and focus more on drafting, detailing, or modeling without unnecessary distractions.

  1. Switch the workspace from existing to 3D Modeling workspace.

Step 3: Extrude the circle:

You can also use push and pull option to extrude your entity. The Push and Pull option in DraftSight allows users to quickly create or modify 3D geometry from 2D shapes. By selecting a face or a closed boundary, you can pull it outward to add material or push it inward to remove material, effectively extruding or cutting the solid. This intuitive tool makes 3D modeling faster and more visual, as you can dynamically adjust the height or depth of features directly in the graphics area. It’s especially useful for quickly turning 2D sketches into 3D models or refining existing designs without needing complex commands.

  1. Set the view to SW Isometric using the view option in the view tab or by the navigator wheel present in the graphical area.
  2. Then select the extrude option from the modelling ribbon in the home tab.
  3. Then select the circle and specify the height 20mm to be extruded.
  4. The extruded circle appears in the graphical area in wireframe visuals.
  5. Go to the visual style manager from the view tab and select the shaded with edges .
  6. You can notice the wireframe visual gets converted to solid visual with shaded edges in the graphical area.

Step 4: Subtract a hole in the 3D model:

  1. Change the UCS by typing UCS ,select the top view through the navigator and select the view option.
  2. Create a cylinder in the centre of the circle.
  3. Specify the centre point and, specify Radius as 20mm and height as 20mm towards downwards.
  4. You can notice the cylinder gets created in the centre of the 3D model.
  5. Select the subtract option from the solid editing ribbon in the home tab . Select the 3D circle first and select the cylinder next . You can notice the hole gets created in the 3D model.

Step 5: Fillet the edges:

  1. Select the fillet edges or type fillet and press enter.
  2. Select the edges need to be filleted in the 3D model and specify the radius and then press enter.
  3. You’ll notice the fillet gets generated in the specified 3D model edges.

Step 6: Create holes and pattern it:

The 3D Pattern feature in DraftSight helps you quickly duplicate 3D objects in a specified arrangement, such as linear, circular, or along a path. It allows you to define the number of instances, spacing, and direction, making it easy to create repetitive features like holes, ribs, or slots. This tool saves significant modeling time by automating the duplication process instead of manually copying and positioning each object. Using 3D Pattern enhances design accuracy and consistency, especially in complex assemblies or symmetrical parts.

  1. Create a cylinder on the top face of the 3D model and specify its height as 20mm downwards and you’ll notice the cylinder gets created.
  2. Select the 3D pattern option and specify the entity(cylinder) ,enter the no .of components needed to be patterned as 4 , specify the angle as 360 degrees ,select the rotation of the component as “no” and specify the centre of axis (two points).
  3. Then select the subtract option and select the 3D model first and select the four patterned cylinders.

Step 7: Modify / move / rotate the solid:

  1. MOVE: select object, pick base point, pick destination.
  2. ROTATE3D (or ROTATE with axis setting): rotate around an axis by degrees .You can also rotate by just pressing “shift” +”left click” +scroll wheel” to rotate your 3D model.
  3. MIRROR3D: create symmetrical features.

Step 8: Section or slice 3D model:

  1. Select the slice option from the ribbon and specify the entity.
  2. Select the two points of your slicing plane and select the point for placing the slicing plane.
  3. And press “Enter” and you’ll notice your 3D model gets sliced or sectioned.

Step 9: Exporting / saving your 3D model:

The DraftSight Connector allows users to seamlessly export and manage their drawings on the 3DEXPERIENCE platform. With this integration, you can directly save your DraftSight files (.dwg or .dxf) to the cloud-based platform, ensuring secure storage and easy access from anywhere. It also enables version control, collaboration, and lifecycle management, allowing team members to review, share, and update drawings efficiently. By exporting to 3DEXPERIENCE, you bridge your DraftSight design workflow with Dassault Systèmes’ digital ecosystem, enhancing teamwork, data security, and project traceability.

  1. To save native: File → Save → .dwg (default).
  2. To export STL for 3D printing: File → Export → STL (choose mesh resolution if prompted).
  3. You can also export your 3D model as “SAT” file for using it in multiple CAD software.

Additional feature : Importing “Step” file :

  1. File → Import → select .stp or .step file (or type IMPORT and choose STEP).
  2. DraftSight will convert the STEP geometry to native solids/surfaces.
https://youtu.be/nZkUD-GtSbs?si=DGR5pRrSDEFoQDK5

Conclusion:

The 3D Workspace in DraftSight converts 2D drafting workflows into a practical 3D modeling pipeline—letting you quickly create primitives, extrude 2D sketches, perform Boolean operations, and edit imported STEP models. By following the steps above you can set up your environment, model parts, clean imported geometry, inspect designs, and export for manufacturing or documentation. Start small (simple primitives and extrudes), practice the key edits (PRESSPULL, SLICE, FILLET), and you’ll gain confidence to handle assemblies and STEP imports effectively. Once comfortable, combine these workflows with DraftSight’s 2D drawing tools to produce complete, production-ready documentation from a single DWG-based environment.
April 28, 2025 0 comments

Batch Printing In Draftsight 2025: Step by Step Guide

DraftSight 2025 is a powerful and user-friendly CAD software designed for professional 2D and 3D design, and one of its key features is the ability to print multiple drawings at once using the batch print function. Whether you need to print a series of engineering drawings, blueprints, or architectural plans, batch printing can save you time and increase productivity.

In this guide, we’ll walk you through the steps to efficiently use the batch printing feature in DraftSight 2025.

What is Batch Printing?

Batch printing allows you to print multiple files (or drawings) simultaneously without opening each individual file. This feature is particularly helpful when you have numerous documents to print in a consistent format and want to streamline your printing workflow.

Why Use Batch Printing in DraftSight 2025?

  • Save Time: Rather than opening each drawing individually and printing them one by one, batch printing allows you to print multiple drawings in one go.
  • Consistency: Batch printing ensures that all the drawings are printed with the same settings and scale.
  • Efficiency: If you have a series of revisions or updates to print, batch printing ensures no files are missed.

Steps to Batch Print in DraftSight 2025

Follow these steps to batch print your files in DraftSight 2025:

  1. Prepare Your Drawings

Before initiating the batch print, make sure all the files you want to print are ready and saved in a specific folder. You can print any number of files, so ensure they are properly named and organized.

batch print

2. Access the Batch Print Feature

To begin the batch printing process:

  • Open DraftSight 2025.
  • Navigate to the File menu and select Batch Print.
  • Alternatively, you can type BATCHPRINT into the command line to quickly access the batch print dialog.

3. Select the Files for Batch Printing

In the Batch Print dialog:

  • Click on Add Files to select the drawings you wish to print. You can choose multiple files from your computer or navigate to the folder where your drawings are stored.
  • You can also use Add Folder if you want to batch print all the files in a specific folder.

4. Choose Print Settings

Once your files are selected, customize the printing settings:

  • Printer Configuration: Select the printer you’ll be using for the batch print.
  • Page Size and Scale: Choose the correct page size and scale for all your drawings. Ensure they’re consistent across all files to avoid misprints.
  • Sheet Orientation: Decide whether the drawings should be printed in portrait or landscape orientation.
  • Plot Style: Select the appropriate plot style (e.g., color, grayscale, monochrome).

5. Choose Output Options

You can also configure output options, such as:

  • Save to PDF: If you prefer to create PDFs instead of printing to a physical printer, DraftSight allows you to select a PDF printer driver.
  • Output Folder: If you are saving the files in a different location or outputting PDFs, choose a folder where the files will be saved.
  • Printing Order: You can specify whether to print files in the order they were added or reverse the order.

6. Start the Batch Print Process

Once all settings are configured, click the Start Plot button. DraftSight will begin the batch printing process and send each drawing to the designated printer or plotter based on your selected settings.

7. Monitor and Complete the Process

The progress of the batch print will be displayed in a status bar. Depending on the number of files and the complexity of the drawings, it may take some time to complete. You can monitor the progress and make adjustments if necessary.

Conclusion:

Batch printing in DraftSight is a powerful feature that can save you valuable time and effort when working with multiple CAD drawings. By setting up your documents and configuring the right print settings, you can easily print a large number of files without having to manage each one separately. Whether you're printing architectural plans, engineering drawings, or any other technical documents, batch printing helps streamline the process and ensures consistency. Keep these tips in mind to get the most out of this useful tool!

Get Quote
June 26, 2024 0 comments

3DEXPERIENCE SOLIDWORKS SHARE AND MARKUP

Share and Mark-up

SOLIDWORKS Share and Markup simplifies design sharing with external stakeholders. They can view, annotate, and share comments on your designs. SOLIDWORKS Share and Markup streamlines collaboration. It allows external stakeholders to interact with your designs by viewing, annotating, and sharing comments. This functionality is available to anyone who has the 3DSwymer, Collaborative Designer for SOLIDWORKS or 3DEXPERIENCE SOLIDWORKS roles.

A key benefit of Share and Markup is that the recipient doesn't need a 3DEXPERIENCE role or SOLIDWORKS license. This allows them to view the file, make notes, and share comments with you directly. All they require, is a 3DEXPERIENCE account, which can be created for no cost. This way, you can avoid the hassle of alternative file sharing tools that can add unnecessary overhead to your design collaboration process.

1. How to enable Share and Markup capabilities

To share files with external recipient some initial setup is required using the Drives Control Center app. The platform Administrator must turn on:

  • Allow platform members to share content with external users by link.
  • Allow external users to view and comment on shared content.

These settings are located on “Share with External” tab.

2. Sharing a file from SOLIDWORKS

In SOLIDWORKS you chose the file format to share. From the “Lifecycle and Collaboration” tab you can select the ‘arrow down’ on the “Share a file” button and then select the desired file format.

In this example 3DXML is chosen, this is the recommended format for sharing an assembly. The 3DXML file will contain all of child components and sub-assemblies.

After choosing the file format, you can create the sharable link. Click the “Share a file” command again and a formatted file is created and placed in your 3DDrive application, in the folder named “Shared with external”.

plus, a dialog box will appear with an option to enable guests to comment on the file, plus an option to restrict access to specific users. If you do NOT enable “restrict access to specific users” anyone with the shared link can access the file.

However, if you activate “Restrict access to specific users” you will have the option to type in the email address of the person you wish to share your file with or multiple email addresses if several persons are to be involved and finally, you can add a message in the dialog box.

However, if you activate “Restrict access to specific users” you will have the option to type in the email address of the person you wish to share your file with or multiple email addresses if several persons are to be involved and finally, you can add a message in the dialog box.

< style="text-align:justify"p>Having applied the required settings, next click the “Share” button, to automatically send an email to your chosen recipient that will include a link to the file and a message.

The recipient will receive an email with a subject line stating the name of the sender, the name of the file, and a link to access the shared file.

A free 3DEXPERIENCE ID account will be prompted to be set up by recipients when they click on the link, if they don’t have one already. If they do have an account, they can just select the link and access the model by signing in to the 3DEXPERIENCE platform. Note: They must use the same email address entered when creating the shared link.

3. Adding annotations and comments to the shared file

Once the recipient has logged in, they can access the model from their browser, which will take them to the shared model in the 3DPlay viewer application, where they can rotate, view, mark up, and comment on it using the intuitive tools in 3DPlay.

All the recipient needs to do is hover over the icons to get a description of the various tools to begin a “mark-up” procedure.

As an example, they can click on the Edit Clipping tool, which cuts through objects using a section plane to view and to access details inside an object, and also to measure hidden items.

4. Sharing annotations and comments with the original sender

A snapshot of the markups/comments can be saved by the recipients upon completion of commenting, by hitting the “Share as Comment” command. This snapshot will then be shown in the Comments window to the right of their screen.

When the feedback has been applied and sent, the original sender will receive a notification from the 3DEXPERIENCE platform.

Clicking on the notification displays the 3DPlay app in the SOLIDWORKS task pane, where of the annotations and comments made by the recipient of the file can be viewed.

5. Understanding where shared files are stored in 3DDrive

The process which has just been described, seems very automatic and simple, and so it is. However, it’s always important to be aware of where the shared files are located, if you, at some point, wish to search for a specific file and other files that might have been shared.

SolidWorks lets you search directly within 3DDrive by opening the application through the Compass.

The 3DDrive application appears and shows all the 3DDrive folders you have access to. Sharing a file like shown in the previous steps automatically creates a folder named "Shared with external" within your "My Files" folder.

This is where all the files you have shared using the “Share a file” feature in SOLIDWORKS are be located.

All the files you have shared from SOLIDWORKS are accessible from this folder. From here you have several options, for example viewing the information of the files you have shared and previewing it so you are able to see exactly what the external recipient is seeing when they open the file in the browser. Deleting the file removes all comments and markups because 3DDrive, not 3DSpace, stores this information.

6. Adding new users to existing shared files

If you want to add more external recipients to collaborate with, you can do it from the folder as well. Just select the desired file, select the share button and then the “Share with external” tab and you get the same window as described previously.

Note: Although there is an expiration date “30 days from link creation” it is only the link to the file that expires, not the file itself. 3DDrive will continue to store the shared file until you remove it.

7. Revoking access to shared files

You have the option to revoke the shared access. When you have located the file you wish to revoke access from in the 3DDrive “Share with external” folder, open the “Share with external” tab in the “Share this file” menu.

Select the “Authorized list”

This feature will display a list of authorized users for the file. You can then select the recycle bin icon next to a user's name to revoke their access.

Share and Markup – use case examples

In this chapter you will find 3 use cases for sharing documents. Consultant designers, suppliers, and manufacturers commonly use these examples in their daily exchange of information.

1. Sharing a SOLIDWORKS drawing

Let’s say you need to share 2D drawing with a supplier. In this case you have made some changes to an original part and would like to get feedback from the supplier.

From the drawing in SOLIDWORKS, you can share the file as PDF, DXF, DWG and PNG.

Having chosen PDF as file format - select “Share a file” again. In this example we will not restrict the access to the file, so we will just make sure that the “Enable guest comments” is active and then click the “Copy external link” followed by “Close”.

The dialogue informs you that the file has been uploaded to 3DDrive upon closing. And if you forget to copy the link before closing the “Share a file” window, there is a Copy Link button in the info pop-up. This pop-up will disappear after a while. Hovering over it, will keep it visible.

You can actively rephrase the sentence as: "We can send the copied link to an external supplier by email."

The external recipient pastes the link into a browser. They can then log in to the 3DEXPERIENCE platform using their account credentials to view the file.

The recipient can now access the drawing and start giving feedback. They can also share comments as described previously.

2. Sharing a design for manufacture

We have approved your design and it is ready for manufacturing. Now you need to send the 3D file. You could send it as a STEP file or as a native SLDPRT file. This can in some cases make it much easier to start producing data for CNC machining or 3D Printing.

Sharing a modified file is easy. Simply select 'Share a file,' and a dialog box will appear allowing you to update the existing file.

Updating the file retains all previous annotations and comments, allowing the communication thread to continue seamlessly.

3. Sharing a large assembly design for review

When dealing with large assemblies, sharing a design efficiently can pose a real challenge as file sizes can get large. In the past, opening a large assembly, even in lightweight mode, often required the recipient to have a workstation running the native CAD application.

This task is now much easier in SOLIDWORKS by utilizing a combination of the 3DXML file format and the Share a File feature.

The 3DEXPERIENCE platform allows you to view 3DXN{L files on both workstations and mobile devices. As long as you access the received link for the shared file — you will be able to open> view> zoom and rotate> explode even complicated assemblies.

Let’s have a look at an example using an all-terrain adventure bike designed by Bowhead Corp.

You have opened the assembly in SOLIDWORKS and prepared it for sharing by selecting 3DXML as the file format.

The sender selects the "Share a file" command and then proceeds to step through the sharing procedure described earlier.

he recipient clicks the link and logs in to 3DEXPERIENCE. They can then easily view the assembly and add comments. This device running a non-Windows operating system took these screenshots.

SOLIDWORKS

Share and Markup compared with traditional methods of file sharing.

Using the Share and Markup workflow can remove the need to use traditional methods of file sharing. Traditional methods of file sharing include PDFs, screenshots of models in documents, and even SolidWorks Pack and Go. These methods often require multiple applications and can cause compatibility issues. Share and markup takes away previously used unstructured workflows and eliminates the typical obstacles in historical file sharing which include:

  • The need for various applications for saving and viewing files.
  • File sizes exceeding mailbox capacity.
  • File formats not compatible with recipient operating system or applications for viewing.

Share and Markup summary

SOLIDWORKS Share and Markup offers a powerful solution for sharing designs with external stakeholders. This functionality leverages the Share a File command and the 3DEXPERIENCE platform. It eliminates the need for less efficient file sharing methods. With SOLIDWORKS Share and Markup, you eliminate the hassle of manual file zipping, email limitations, and recipient software downloads. Now, anyone can view and comment on your designs using a simple web link. The 3DEXPERIENCE platform lets you work through your browser. This allows recipients to view and add comments to shared files on a mobile device.

SOLIDWORKS Share and Markup streamlines design collaboration. Designers and stakeholders can work together efficiently, getting products to market faster.
June 24, 2024 0 comments

3DEXPERIENCE SOLIDWORKS SHARE AND MARKUP

SOLIDWORKS Share and Markup simplifies design sharing with external stakeholders. They can view, annotate, and share comments on your designs. SOLIDWORKS Share and Markup streamlines collaboration. It allows external stakeholders to interact with your designs by viewing, annotating, and sharing comments. This functionality is available to anyone who has the 3DSwymer, Collaborative Designer for SOLIDWORKS or 3DEXPERIENCE SOLIDWORKS roles.

A key benefit of Share and Markup is that the recipient doesn't need a 3DEXPERIENCE role or SOLIDWORKS license. This allows them to view the file, make notes, and share comments with you directly. You only need a 3DEXPERIENCE account, which is free to create. This way, you can avoid the hassle of alternative file sharing tools that can add unnecessary overhead to your design collaboration process.

1. How to enable Share and Markup capabilities

To share files with external recipient some initial setup is required using the Drives Control Center app. The platform Administrator must turn on:

  • Allow platform members to share content with external users by link.
  • Allow external users to view and comment on shared content.

These settings are located on “Share with External” tab.

2. Sharing a file from SOLIDWORKS

In SOLIDWORKS you chose the file format to share. From the “Lifecycle and Collaboration” tab you can select the ‘arrow down’ on the “Share a file” button and then select the desired file format.

In this example 3DXML is chosen, this is the recommended format for sharing an assembly. The 3DXML file will contain all of child components and sub-assemblies.

After choosing the file format, you can create the sharable link. Click the “Share a file” command again and a formatted file is created and placed in your 3DDrive application, in the folder named “Shared with external”.

plus, a dialog box will appear with an option to enable guests to comment on the file, plus an option to restrict access to specific users. If you do NOT enable “restrict access to specific users” anyone with the shared link can access the file.

However, if you activate “Restrict access to specific users” you will have the option to type in the email address of the person you wish to share your file with or multiple email addresses if several persons are to be involved and finally, you can add a message in the dialog box.

Having applied the required settings, next click the “Share” button, to automatically send an email to your chosen recipient that will include a link to the file and a message.

The recipient will receive an email with a subject line stating the name of the sender, the name of the file, and a link to access the shared file.

When recipients click on the link, they will be prompted to set up a free 3DEXPERIENCE ID account, if they don’t have one already. If they do have an account, they can just select the link and access the model by signing in to the 3DEXPERIENCE platform. Note: They must use the same email address entered when creating the shared link.

3. Adding annotations and comments to the shared file

Once the recipient has logged in, they can access the model from their browser, which will take them to the shared model in the 3DPlay viewer application, where they can rotate, view, mark up, and comment on it using the intuitive tools in 3DPlay.

All the recipient needs to do is hover over the icons to get a description of the various tools to begin a “mark-up” procedure.

As an example, they can click on the Edit Clipping tool, which cuts through objects using a section plane to view and to access details inside an object, and also to measure hidden items.

4. Sharing annotations and comments with the original sender

Recipients can save their markups/comments as a snapshot by hitting the "Share as Comment" command. This will then display the snapshot in the Comments window on the right side of their screen.

The 3DEXPERIENCE platform will notify the original sender when the feedback has been applied and sent.

Clicking on the notification displays the 3DPlay app in the SOLIDWORKS task pane, where of the annotations and comments made by the recipient of the file can be viewed.

5. 3DDrive: Locating Shared Files

The process which has just been described, seems very automatic and simple, and so it is. However, it’s always important to be aware of where the shared files are located, if you, at some point, wish to search for a specific file and other files that might have been shared.

By opening the 3DDrive application, searching can be performed in SolidWorks as well, simply locating the 3DDrive application through the Compass and open it.

The 3DDrive application appears and shows all the 3DDrive folders you have access to. When you share a file like shown in previous steps, the folder “Shared with external” is automatically created and to be found in the “My Files” folder.

This is where all the files you have shared using the “Share a file” feature in SOLIDWORKS are be located.

All the files you have shared from SOLIDWORKS are accessible from this folder. From here you have several options, for example viewing the information of the files you have shared and previewing it so you are able to see exactly what the external recipient is seeing when they open the file in the browser.We recommend deleting the file, but be aware that this will also remove all comments and markups attached to it. The 3DDrive file, not the copy in your 3DSpace, stores this information

6. Adding new users to existing shared files

If you want to add more external recipients to collaborate with, you can do it from the folder as well. Just select the desired file, select the share button and then the “Share with external” tab and you get the same window as described previously.

Note: Although there is an expiration date “30 days from link creation” it is only the link to the file that expires, not the file itself. We will keep the shared file in the 3DDrive until we remove it.

7. Revoking access to shared files

You have the option to revoke the shared access. When you have located the file you wish to revoke access from in the 3DDrive “Share with external” folder, open the “Share with external” tab in the “Share this file” menu.

Select the “Authorized list”

This program will show you the list of authorized users for this file. You can then select the recycle bin icon next to a user to revoke their access.

Share and Markup – use case examples

In this chapter you will find 3 use cases for sharing documents. These examples are commonly used by consultant designers, suppliers, and manufacturers in their daily information exchange.

1. Sharing a SOLIDWORKS drawing

Let’s say you need to share 2D drawing with a supplier. In this case you have made some changes to an original part and would like to get feedback from the supplier.

From the drawing in SOLIDWORKS, you can share the file as PDF, DXF, DWG and PNG.

Having chosen PDF as file format - select “Share a file” again. In this example we will not restrict the access to the file, so we will just make sure that the “Enable guest comments” is active and then click the “Copy external link” followed by “Close”.

The dialogue closes with a message stating that you have uploaded the file to 3DDrive. And if you forget to copy the link before closing the “Share a file” window, there is a Copy Link button in the info pop-up. This pop-up will disappear after a while. Hovering over it, will keep it visible.

We can send the copied link to an external supplier by email.

The external recipient pastes the link into a browser. They can then log in to the 3DEXPERIENCE platform using their account credentials to view the file.

The recipient can now access the drawing and start giving feedback. They can also share comments as described previously.

2. Sharing a design for manufacture

We have approved your design and it is ready for manufacturing. Now you need to send the 3D file. You could send it as a STEP file or as a native SLDPRT file. This can in some cases make it much easier to start producing data for CNC machining or 3D Printing.

We can easily share a file after making modifications. Simply select 'Share a file' and a dialog box will appear, allowing you to update the existing file.

The update process retains all previous annotations and comments, allowing the communication thread to continue seamlessly.

3. Sharing a large assembly design for review

When dealing with large assemblies, sharing a design efficiently can pose a real challenge as file sizes can get large. Previously, opening a large assembly, even in lightweight mode, often required recipients to use a workstation with the native CAD application installed.

This task is now much easier in SOLIDWORKS by utilizing a combination of the 3DXML file format and the Share a File feature.

The 3DEXPERIENCE platform allows you to view 3DXML files on both workstations and mobile devices. As long as you access the received link for the shared file – you will be able to open, view, zoom and rotate, explode even complicated assemblies.

Let’s have a look at an example using an all-terrain adventure bike designed by Bowhead Corp.

I have opened the assembly in SOLIDWORKS and prepared it for sharing by selecting 3DXML as the file format.

The user selects the "Share a file" command and then proceeds to follow the sharing procedure outlined earlier.

The recipient clicks the link and logs in to 3DEXPERIENCE. They can then easily view the assembly and add comments. A non-windows device took these screenshots.

Share and Markup compared with traditional methods of file sharing.

Using the Share and Markup workflow can remove the need to use traditional methods of file sharing. Traditional methods of file sharing include PDFs, screenshots of models in documents, and even SolidWorks Pack and Go. These methods often require multiple applications and can cause compatibility issues. Share and markup takes away previously used unstructured workflows and eliminates the typical obstacles in historical file sharing which include:

  • The need for various applications for saving and viewing files.
  • File sizes exceeding mailbox capacity.
  • File formats not compatible with recipient operating system or applications for viewing.

1. Share and Markup summary

SOLIDWORKS Share and Markup offers a powerful solution for sharing designs with external stakeholders. This functionality leverages the Share a File command and the 3DEXPERIENCE platform. It eliminates the need for less efficient file sharing methods. With SOLIDWORKS Share and Markup, you eliminate the hassle of manual file zipping, email limitations, and recipient software downloads. Now, anyone can view and comment on your designs using a simple web link. The browser supports the 3DEXPERIENCE platform. This allows recipients to view and add comments to shared files on a mobile device.

SOLIDWORKS Share and Markup streamlines design collaboration. Designers and stakeholders can work together efficiently, getting products to market faster.

June 22, 2024 0 comments

3D PRINTERS & 3D SCANNERS

Additive Manufacturing

3D  PRINTER

SIMTEK provides a range of services, including part manufacturing, modeling, and other engineering services. SIMTEK embraces the latest technology of additive manufacturing and prototypes for product visualisation and creation.

Our goal is to offer a solution that is cost effective, maintainable and expandable for our customers

Digital manufacturing is replacing conventional manufacturing methods it allows for efficient prototyping and tool production, product visualisations and mass communication with no waste of materials and no tooling required. The two main activities of the company are software solutions development, information technology services & training

.

    GET A QUOTE

    OUR SERVICES

    • Rapid Prototyping
    • Detail Drafting
    • 2D to 3D CAD Conversion
    • 3D Solid Modelling
    • Conceptual Design
    • Technical Communication
    • Facility Planning
    • Reverse Engineering

    3d printer

    3d scanner

    Benefits of Implementing 3D Printing Technology



    • Reduced manufacturing costs by eliminating tooling and setup expenses.
    • Optimization of the supply chain through decentralized manufacturing.
    • Improved inventory management with just-in-time production.
    • Design complexity and innovation with freedom in design.
    • Sustainability and waste reduction through minimal material usage.
    • On-demand production for smaller batch sizes and spare parts manufacturing.
    • Provide services right from Designing - Scanning - Pre-Processing - 3D Printing - Post Processing.

    INDUSTRIES WE SERVE

    • Mining
    • Defence
    • Power Generation
    • Medical and dental
    • General Engineering
    • Education
    • Architecture
    • Oil & Gas
    • Automotive & Petroleum
    • Aerospace

    3d scanner and printer

    3D scanner

    3D scanning is a technology that is changing manufacturing and engineering processes in every industry. It have become indispensable tools across various industries, providing the flexibility to scan objects in real-world environments. Now, imagine combining the portability of handheld devices with the sophistication of hybrid light sources. The result is a multifunctional powerhouse capable of addressing a wide array of scanning needs, from manufacturing and healthcare to cultural heritage preservation and virtual reality applications.

    Benefits of 3D Scanner

    • Able to scan tough surfaces, such as shiny or dark finishes
    • Less sensitive to changing light conditions and ambient light
    • Very fast scan times – as fast as 2 seconds per scan
    • Large scanning area – as large as 48 inches in a single scan
    • Very high accuracy – as high as 10 microns (.00039”)
    • Various price points from low cost to expensive depending on resolution and accuracy
    • Small to large parts can be measured with the proper machine
    • Ability to probe and scan even while the part is moving with no loss of accuracy
    • Precise, high-speed as built documentation

    3d scanner

    3d scanner

    Why buy 3D Scanner from SIMTEK?

    • Experienced laser scanning professionals
    • Fast mobilization and data collection
    • Highest quality, industry-leading laser scanners
    • Optimized workflows to reduce project completion time
    • We offer a 24-hour replacement 3D scanner in the event of technical difficulties during usage.
    • We provide round the clock post sales support
    • Offer a three-phase training program (basic, intermediate and advanced) for your product

    OUR SERVICES

    • 3D scanning (Laser scanning / Structured light scanning)
    • CT scanning (STL data output & Reverse engineering)
    • Scan to CAD data (reverse engineering)
    • CMM Inspection
    • 3D Inspection
    • Jigs and fixture inspection and correction
    • Scan to cad data conversion (STL to step format)
    • Jigs and fixture manufacturing

    3d scanner

    Streamline Your 3D Printed Product Development with 3D Product Architect (PAU)
    January 10, 2024 0 comments

    Streamline Your 3D Printed Product Development with 3D Product Architect (PAU)

    Streamline Your 3D Printed Product Development with 3D Product Architect (PAU)

    Struggling to manage complex 3D printed product designs across multiple design tools? Look no further than 3D Product Architect (PAU), a revolutionary browser-based application that empowers seamless collaboration and streamlines the entire 3D printed product development process.

    3D Product Architect enables users to create or modify multi-CAD product structures without the use of design tools. Being able to digitally mockup a proposal reduces design iterations and makes reviews available to the product development process.

    1. Connect everyone with the product development process using a browser-based application.
    2. Enable non-CAD users to mock-up new products or product changes prior to the detailed design.
    3. Create multi-CAD mock-ups of a product.
    4. Optimize the product definition for configurable products into a single definition that satisfies the intent of product variations and maximizes IP reuse.

    Beyond the Basics: Advanced Features for Efficiency:

    3D PAU offers a robust set of features to optimize your 3D printed product development workflow:

    • Effortless 3D Visualization: Visualize and navigate your entire product structure in 3D, allowing for a comprehensive understanding of the design and the impact of any changes.
    • Intuitive Product Development: Create, modify, or derive new product structures directly from your web browser. Utilize drag-and-drop functionality and free-form tools for effortless product assembly.
    • Digital Mock-up Made Easy: Effortlessly build digital mockups within the browser and seamlessly transfer them to your preferred CAD software.
    • Work Under Change Management: Maintain complete control over design revisions. The "Work Under Change" feature captures all modifications within a designated change action, ensuring clear audit trails.

    Key functionalities of 3D PAU include::

    1. CAD Visualization
    2. 3D Visualization
    3. Product Development
    4. Work Under Change
    5. Digital Mock-up
    6. Derivative Product Development
    7. Measurement and Sectioning
    8. Related Products and Specifications
    9. Product Structure Filtering

    Unleash the Power of Collaboration

    • Effortless 3D Visualization: Visualize and navigate your entire product structure in 3D, allowing for a comprehensive understanding of the design and the impact of any changes.
    • Intuitive Product Development: Create, modify, or derive new product structures directly from your web browser. Utilize drag-and-drop functionality and free-form tools for effortless product assembly.
    • Digital Mock-up Made Easy: Effortlessly build digital mockups within the browser and seamlessly transfer them to your preferred CAD software.
    • Work Under Change Management: Maintain complete control over design revisions. The "Work Under Change" feature captures all modifications within a designated change action, ensuring clear audit trails.

    Beyond the Basics: Advanced Features for Efficiency

    3D PAU offers a robust set of features to optimize your 3D printed product development workflow:

    Effortless Derivative Product Development: Duplicate existing products to create variations, selectively reusing components and streamlining the design process.

    Precise Measurement and Sectioning: Perform detailed measurements, create sections for design clarity, and locate specific features within your product structure.

    Enhanced Navigation with Related Products and Specifications: Effortlessly navigate the relationships between product components, change actions, and other specifications.

    Streamlined Filtering: Utilize volume queries to isolate specific sections of your product structure, simplifying the visualization of complex designs.

    Revolutionize Your 3D Printing Workflow with 3D PAU

    3D PAU empowers efficient collaboration, streamlines product development, and simplifies 3D printed product design for users of all experience levels. Experience the future of 3D printed product development with 3D PAU.

    June 23, 2021 0 comments

    SOLIDWORKS 3D CAD

    SOLIDWORKS 3D CAD

    Software and Product Design Tools

    SOLIDWORKS 3D CAD– The Best Software for Design

    If you are an assembly, product or part designer, then SOLIDWORKS 3D CAD is your companion for success. The tool suite is highly intuitive, comprehensive, and intelligent, thereby reducing your effort requirements in designing products, components, parts, assemblies, or anything else! Go on to deliver solutions that reflect the talent and are future-proof in design and operation. We empower you to fly high as you seek to push the limits of 3D modelling design.

    Get a Demo

    Adding Cloud to 3D CAD Work

    SOLIDWORKS helps add cloud to 3D CAD work and empowers users by

    • Supporting 3D printing
    • Offering secure solutions for data
    • Analysis of forces and measurements
    • Analysis for manufacture
    • Validation with FEA and CFD tools
    • Export options for use in different areas
    • Helping build technical documentation

    Why Is SOLIDWORKS the Right Choice?

    SOLIDWORKS 3D CAD is the acclaimed champion in 3D CAD and has an intuitive easy-to-use interface, a superb spread of capabilities and features and ability to be used in multiple projects for different purposes. It is often the chosen choice for all design needs, whether large or small enterprises, universities, or technical schools, and the software takes pride in delivering successful solutions on the ground when the plans are turned to reality.

    SOLIDWORKS PACKAGES

    Get up to speed quickly with SOLIDWORKS Standard and unlock the benefits of this powerful 3D design solution for the rapid creation of parts, assemblies, and 2D drawings. Application-specific tools for sheet metal, weldments, surfacing, and mold tool and die, make it easy to deliver best-in-class designs.

    SOLIDWORKS Professional builds on the capabilities of SOLIDWORKS Standard to increase design productivity, with file management tools, advanced photorealistic rendering, automated cost estimation, eDrawings® Professional collaboration capabilities, automated design and drawing checking, plus a components & parts library.

    SOLIDWORKS Premium is a comprehensive 3D design solution that adds powerful simulation and design validation to the capabilities of SOLIDWORKS Professional, as well as ECAD/MCAD collaboration, reverse engineering, and advanced wire and pipe routing functionality for all types of industry product and part 3D modeling.

    COMPARE SOLIDWORKS PACKAGES

    SOLIDWORKS
    Standard    		 SOLIDWORKS
    Professional    		 SOLIDWORKS
    Premium
    SOLIDWORKS 3D CAD
    Part and Assembly Modeling
    2D Drawings
    Design Reuse and Automation
    Collaborate and Share CAD Data
    Interference Check
    First-Pass Analysis Tools
    CAM Programming (SOLIDWORKS CAM Standard)
    *must be current on Support
    Design for Manufacturing (DFM)
    Productivity Tools
    Advanced CAD File Import/Export and Interconnect
    CAD Libraries(SOLIDWORKS toolbox)
    Design for Cost (SOLIDWORKS costing)
    ECAD/MCAD collaboration (CircuitWorks)
    CAD Standards Checking (Design Checker)
    Collaboration with eDrawings Professional
    Automated Tolerance Stack-Up Analysis (TolAnalyst)
    Advanced Photorealistic Rendering (SOLIDWORKS Visualize Standard)

    *must be current on Support
    SOLIDWORKS File Management
    Reverse Engineering (Scanto3D)
    Time-Based Motion Analysis
    Linear Static Analysis for Parts and Assemblies
    Pipe and Tube Routing
    Electrical Cable and Wiring Harness Routing
    Advanced Surface Flattening
    Rectangular and Other Section Routing
    CATIA V5 Import
    Get a Quote
    March 5, 2026 0 comments

    Reverse Engineering

    Reverse Engineering Services in Chennai

    Turn Physical Components into Accurate, Production-Ready Digital Assets

    BOOK YOUR SERVICE NOW

    High-Precision 3D Scanning & Industrial 3D Printing for Manufacturing Excellence

    Missing CAD files? Obsolete spare parts? Production delays due to discontinued components?

    We provide professional reverse engineering services in Chennai with advanced 3D scanning and industrial 3D printing solutions to help automotive, heavy engineering, and industrial manufacturers regain full control over their product data.

    From high-accuracy 3D scanning and point cloud to CAD conversion to rapid prototyping with 3D printing, we deliver end-to-end engineering solutions that reduce downtime, accelerate redesign cycles, and improve manufacturing efficiency.

    • Industrial-Grade 3D Scanning
    • Parametric CAD Reconstruction
    • Rapid Prototyping & Functional 3D Printing
    • Automotive & Heavy Engineering Expertise
    • Serving Chennai, Sriperumbudur, Oragadam & Across Tamil Nadu
    BOOK YOUR SERVICE NOW

    Reverse Engineering – Get3D Labs

    Looking for Reverse Engineering Services When CAD Files or Improve a Critical Component?

    Many engineering teams and manufacturers begin searching for reverse engineering services when they face a common but urgent problem — a part needs to be recreated, improved, or analyzed, but the original design data is missing or incomplete.

    This situation is especially common in industries such as automotive manufacturing, heavy engineering, industrial machinery, tooling, and fabrication, where machines often operate for years and documentation may not always be available in digital form.

    When organizations start looking for Best reverse engineering services in Chennai, it is usually because they are facing one or more of the following challenges:

    A Critical Component Needs to Be Recreated

    A machine part fails or wears out, but the original CAD model or technical drawing is unavailable. Without accurate design data, reproducing the component becomes difficult and can delay production.

    Legacy Equipment Requires Spare Parts

    Many manufacturers continue to operate older machines that are no longer supported by the original suppliers. In these situations, companies need reverse engineering and 3D scanning services to recreate spare parts and maintain operational continuity.

    Existing Designs Need Improvement

    Organizations may want to optimize existing products by reducing weight, improving strength, or modifying geometry. However, without access to parametric CAD models, engineering teams cannot efficiently redesign or enhance the component.

    Complex Geometries Are Difficult to Measure Manually

    Modern mechanical components often include complex surfaces and intricate shapes that are difficult to capture accurately using traditional measurement methods. This is where advanced 3D scanning and digital reconstruction become essential.

    Product Development Needs Accurate Digital Models

    For companies working on product redesign, simulation, or prototype validation, having accurate CAD data is critical. Reverse engineering allows physical parts to be converted into precise digital models that can be modified, analyzed, and manufactured again.

    Why Companies Choose Professional Reverse Engineering Services

    When manufacturers partner with an experienced engineering service provider, they gain the ability to convert physical components into accurate digital assets using advanced technologies such as industrial 3D scanning, point cloud processing, CAD reconstruction, and 3D printing for rapid prototyping.

    This approach helps organizations:

    • Recreate discontinued or unavailable parts
    • Digitize legacy components into parametric CAD models
    • Improve existing designs and product performance
    • Reduce production downtime caused by missing components
    • Accelerate product development and engineering workflows
    BOOK YOUR SERVICE NOW

    Ingeniería inversa para maquinaria y procesos | ALTERTECNIA

    Industries We Support with Reverse Engineering and 3D Scanning Services in Chennai

    Our engineering and reverse engineering services in Chennai with industrial 3D scanning, CAD reconstruction, and rapid prototyping support a wide range of manufacturing and product development organizations. We work closely with companies that need accurate digital models, component recreation, and engineering design support for complex mechanical parts.

    Our solutions are commonly used by:

    • Automotive component manufacturers who require reverse engineering and 3D scanning services to recreate or improve mechanical parts and assemblies.

    • Industrial machinery manufacturers looking to digitize legacy components, reproduce discontinued parts, or optimize existing equipment designs.

    • Tooling, mold, and die manufacturers who need high-precision CAD models generated through reverse engineering for tooling modification and manufacturing.

    • Product development startups and engineering teams that require accurate CAD data, rapid prototyping, and design validation during product development.

    • Fabrication and sheet metal companies seeking digital models of components for redesign, manufacturing improvements, or documentation.

    By supporting these industries with professional reverse engineering services, point cloud to CAD conversion, and 3D scanning solutions for mechanical components, we help organizations improve design accuracy, reduce production delays, and maintain reliable engineering data for future manufacturing needs.

    Why Manufacturers Choose Our Reverse Engineering Services in Chennai

    Companies searching for professional reverse engineering services in Chennai with industrial 3D scanning and CAD reconstruction for mechanical components need a reliable engineering partner who understands real manufacturing requirements and delivers accurate, production-ready results.

    Industry Experience in Manufacturing and Engineering

    We support organizations across multiple sectors including automotive manufacturing, industrial machinery, aerospace components, tooling, fabrication, and mechanical product development. Our team understands the engineering challenges involved in recreating and improving complex industrial parts.

    Advanced Reverse Engineering Technologies

    Our industrial reverse engineering services with high-precision 3D scanning, point cloud to CAD conversion, and parametric CAD modeling enable manufacturers to transform physical components into accurate digital engineering models.

    Faster Turnaround for Critical Components

    Our streamlined workflow for reverse engineering and 3D scanning services for mechanical parts and legacy components helps companies recreate or improve critical components quickly, reducing machine downtime and production delays.

    Reliable CAD Models for Engineering and Manufacturing

    We deliver high-accuracy CAD models generated through professional reverse engineering and 3D scanning services, allowing engineering teams to use the data for product redesign, simulation, prototyping, and future manufacturing.

    Our Comprehensive Reverse Engineering Services

    3D Scanning and Digitization

    We employ state-of-the-art 3D scanning technologies to capture precise geometric data of physical objects. Specifically, we use:

    • High-resolution laser scanning
    • Structured light scanning
    • Photogrammetry for large objects
    • CT scanning for internal geometries

    These technologies allow us to ensure accuracy and efficiency in our data capture process.

    CAD Reconstruction

    Our skilled engineers transform scan data into accurate, editable 3D CAD models. Specifically, we offer:

    • Surface modeling for complex shapes
    • Solid modeling for mechanical parts
    • Parametric modeling for design intent capture
    • Assembly modeling for multi-component products

    Additionally, these services ensure precision and flexibility, enabling high-quality and efficient design workflows.

    Dimensional Analysis

    We provide detailed dimensional analysis to ensure accuracy and compliance:

    • GD&T (Geometric Dimensioning and Tolerancing) analysis
    • Comparison to original design specifications
    • Deviation analysis and reporting
    Material Analysis

    Our material analysis services help identify and characterize materials:

    • Composition analysis using spectroscopy
    • Mechanical property testing
    • Microstructure analysis
    Functional Analysis

    We delve deep into how products work, providing:

    • Kinematic and mechanism analysis
    • Performance evaluation and benchmarking
    • Failure analysis and root cause identification
    Design Optimization

    Based on our analysis, we offer suggestions for design improvements:

    • Weight reduction strategies
    • Performance enhancement recommendations
    • Manufacturing process optimization
    Industry Applications

    Our reverse engineering services cater to a wide range of industries. Specifically:

    • Automotive: This includes legacy part reproduction and competitor analysis.
    • Aerospace: We specialize in obsolete component replication and aircraft maintenance.
    • Manufacturing: Our services cover tooling and fixture design, as well as process improvement.
    • Consumer Products: We offer product benchmarking and design evolution.
    • Medical Devices: This includes custom implant design and device improvement.
    • Heritage Preservation: We focus on historical artifact digitization and replication.

    These diverse applications highlight our comprehensive capabilities and dedication to meeting industry-specific needs.

    Get Reliable Reverse Engineering and 3D Scanning Services for Your Engineering Needs

    If your organization is facing challenges such as missing CAD files, obsolete machine components, or the need to improve an existing product design, professional reverse engineering can provide the solution. Our team delivers professional reverse engineering services in Chennai with high-precision 3D scanning, point cloud to CAD conversion, and industrial 3D printing for mechanical components and manufacturing industries. We help engineering teams convert physical parts into accurate digital models that can be redesigned, optimized, and manufactured with confidence. Whether you need to recreate a discontinued component, digitize legacy equipment parts, or accelerate product development through rapid prototyping, our engineering specialists ensure every project is handled with precision and technical expertise.

    With our end-to-end capabilities in reverse engineering, industrial 3D scanning, CAD reconstruction, and 3D printing services for manufacturing companies, we support organizations in reducing downtime, improving design control, and maintaining long-term digital engineering assets.

    How Our Engineering Services Help

    We support companies at every stage of product development:

    • Convert product ideas into 3D CAD models
    • Validate designs using engineering simulation
    • Recreate existing parts using reverse engineering
    • Improve manufacturability and reduce design errors
    BOOK YOUR SERVICE NOW

    FAQ's

    How accurate are your reverse engineering and CAD modelling services?

    Our engineering team follows industry-standard workflows and uses advanced CAD reconstruction techniques to ensure highly accurate digital models. Every CAD file is carefully validated so manufacturers can confidently use the design data for redesign, analysis, or production.

    Can you recreate CAD models if original design files are completely missing?

    Yes. Our reverse engineering services are specifically designed for situations where original CAD files, drawings or documentation are unavailable. Using advanced engineering methods and design reconstruction processes, we can recreate precise CAD models from physical components, samples or reference data.

    How quickly can you deliver CAD models or engineering drawings?

    Project timelines depend on component complexity, assembly size and required detailing. However, our structured engineering workflow allows us to deliver accurate CAD models and technical drawings within optimized timelines so manufacturers can continue production without delays.

    Do you support modifications and redesign of existing components?

    Yes. Along with reverse engineering, we also support design optimization, part modification, and product improvement. This helps manufacturers upgrade existing products, improve performance, or adapt designs for new manufacturing processes.

    What industries do you typically work with?

    Our engineering services support manufacturers across multiple industries including automotive components, industrial machinery, tooling and mold manufacturing, fabrication companies and product development teams.

    What types of objects can you reverse engineer?

    We can reverse engineer a wide range of objects, from small precision components to large industrial machinery. Moreover, our diverse scanning technologies allow us to capture data from various materials and sizes, ensuring comprehensive and precise results.

    How accurate are your reverse engineered models?

    Our models typically achieve accuracies within 0.025mm to 0.1mm, depending on the object’s size and complexity. Consequently, we always strive for the highest possible accuracy and validate our results against the original object to ensure precision and reliability.

    Can you reverse engineer internal components?

    Yes, we use CT scanning technology to capture internal geometries without destructive testing. Moreover, this is particularly useful for complex assemblies, especially when non-invasive analysis is required.

    How do you handle intellectual property concerns in reverse engineering?

    We strictly adhere to ethical reverse engineering practices and respect intellectual property rights. Furthermore, we work within legal frameworks and can sign NDAs to protect your interests. Additionally, our services focus on understanding and improving designs, rather than infringing on patents.

    Can you help with obsolete or out-of-production parts?

    Absolutely! One of the key applications of our reverse engineering services is recreating obsolete parts for which no original documentation exists. Moreover, we can help you bring these parts back into production with modern manufacturing methods, thereby ensuring their functionality and reliability. Additionally, our expertise guarantees that these recreated parts meet contemporary standards and specifications.

    April 8, 2025 0 comments

    social media

    Authorized 3DEXPERIENCE SOLIDWORKS Reseller in India

    SIM TECHNOLOGIES is an Authorized SOLIDWORKS & 3DEXPERIENCE Works reseller and engineering solution provider in Chennai, Coimbatore and Kolhapur. We are also an authorized SOLIDWORKS Training and SOLIDWORKS Certification center in Tamilnadu. We support our customers with SOLIDWORKS Technical Training & SOLIDWORKS Webinars at various locations in Tamilnadu.

    Everything we do is focused on close collaboration and engagement with our consumers. SIMTEK delivers best-in-class design solutions that are easy to use, administer, and interface with other platforms, with over 25 years of expertise and 1000+ customers in high tech, medical, machine design, energy and other industries. We are also proud to serve academic institutions as the Regional champion for colleges, universities and schools.

    As an electric beehive of ideas, we also deliver strong and transformative solutions in design, simulation, product data management, manufacturing, reverse engineering, finite element analysis, value engineering and CAD modifications as a best SOLIDWORKS Reseller in India.

      Best Authorized SOLIDWORKS Reseller in Chennai, Coimbatore & Kolhapur

      Get affordable SOLIDWORKS software pricing and deals in Chennai with certified training & technical support

      1000+ Clients

      Trusted by leading businesses for reliable SOLIDWORKS solutions.

      3 Office Locations

      Serving businesses across Tamil Nadu & Kolhapur with dedicated SOLIDWORKS support.

      100+ Industry Awards

      Honored for outstanding SOLIDWORKS expertise, service and innovation.

      25+ Years Experience

      Serving businesses with expert SOLIDWORKS solutions.

      Schedule Demo
      Request Quote

      OUR CLIENTS

      OUR SERVICES

      CAD SERVICES

      As the best authorized SOLIDWORKS reseller in Chennai and Coimbatore, we provide SOLIDWORKS 3D CAD solutions for product modeling, drafting and assembly design. Our CAD services help engineering firms and manufacturers streamline design-to-production workflows, automate repetitive tasks and improve collaboration.

      Learn more>>

      CAE SERVICES

       With SOLIDWORKS Simulation, we offer structural analysis, thermal simulation and motion studies to enhance product durability and efficiency. Our affordable SOLIDWORKS software pricing in Chennai and Coimbatore ensures businesses get cost-effective solutions for stress testing and design validation.

      Learn more>>

      REVERSE ENGINEERING

      We use high-precision 3D scanning to convert physical parts into detailed 3D CAD models, ideal for legacy part recreation, design modifications and industrial upgrades. Our expertise helps manufacturing companies in Chennai and Coimbatore optimize production.

      Learn more>>

      3D PRINTERS & 3D SCANNERS

      AGet top-rated 3D printers and scanners for rapid prototyping, product validation, and quality inspection. We offer affordable SOLIDWORKS subscription services with flexible licensing for seamless integration

      Learn more>>

      CAD/ CAE SOFTWARE SOLUTIONS FROM DESIGN TO MANUFACTURING



      SOLIDWORKS

      SOLIDWORKS is a cutting-edge 3D CAD tool and industrial design software for today's quality product design professionals
      LEARN MORE >

      3DEXPERIENCE Works

      The 3DExperience is an integrated platform based on the cloud. It facilitates collaborative working and brings all aspects of the development together.
      LEARN MORE >

      DRAFTSIGHT

      Draftsight is versatile software offering 2D computer-aided drafting for all engineering services including, mechanical, manufacturing,
      LEARN MORE >

      INDUSTRIES USING 3DEXPERIENCE SOLIDWORKS

      SIMTEK solutions to Aerospace & Defense Industry

      Aerospace & Defense

      SIMTEK solutions to Energy & materials Industry
      Energy & Materials

      SIMTEK solutions to Government projects
      Government

      SIMTEK solutions to High Tech Industry
      High-Tech

      SIMTEK solutions to Home & Lifestyle Industry
      Home & Lifestyle

      SIMTEK solutions to Life science & healthcare Industry



      Life Sciences & Healthcare

      SIMTEK solutions to Marine & Offshore Industry



      Marine & Offshore

      SIMTEK solutions to Industrial equipment design Industry
      Industrial Equipment Design

      SIMTEK solutions to Transportation, automotive & mobility industry
      Transportation & Mobility

      Aerospace & Defense

      Energy & Materials

      Government

      High-Tech

      Home & Lifestyle

      Life Sciences & Healthcare

      Marine & Offshore

      Industrial Equipment Design

      Transportation & Mobility

      SOLIDWORKS Portfolio

      As the best authorized SOLIDWORKS reseller in Chennai, Coimbatore and Kolhapur. SIMTEK provides a comprehensive SOLIDWORKS solution to optimize design, simulation, manufacturing and data management for businesses and engineering firms.

       DESIGN

      Leverage SOLIDWORKS 3D CAD software for precise product modeling, assembly design and drafting. Our affordable SOLIDWORKS pricing in Chennai, Coimbatore and Kolhapur ensures businesses get the best CAD solutions for product development.





      Learn more>>

      SIMULATION

      With SOLIDWORKS Simulation, conduct stress analysis, thermal evaluation, and motion studies to improve product reliability and cost-effectiveness. Ideal for engineering firms and manufacturers in Chennai, Coimbatore and Kolhapur.







      Learn more>>

      DATA MANAGEMENT

      Manage engineering data, PDM workflows and product lifecycle using SOLIDWORKS PDM and 3DEXPERIENCE solutions. Get seamless collaboration, version control and secure data management for better project execution.



      Learn more>>

      MANUFACTURE

      Optimize CNC machining, production and quality control with SOLIDWORKS CAM, MBD and Inspection tools. Our SOLIDWORKS implementation and consultation services in Chennai, Coimbatore and Kolhapur help industries achieve efficient manufacturing workflows.





      Learn more>>

      MARKETING

      Create high-quality 3D renderings, animations and interactive product experiences with SOLIDWORKS Visualize and Composer. Our certified SOLIDWORKS training centers in Chennai & Coimbatore ensure businesses maximize their marketing and sales potential.



      Learn more>>

      3DEXPERIENCE Portfolio

      As the Trusted SOLIDWORKS reseller in Chennai, Coimbatore and Kolhapur, SIMTEK offers 3DEXPERIENCE solutions that integrate design, simulation, data management and smart manufacturing to enhance product development and business efficiency.

       DESIGN

      3DEXPERIENCE SOLIDWORKS provides a cloud-based 3D CAD environment with seamless collaboration, real-time data access, and integrated project management, helping teams accelerate product design and innovation.



      Learn more>>

      SIMULATION

      Perform high-end simulations with SIMULIA, enabling engineers to analyze stress, heat transfer, fluid dynamics and complex physics-based scenarios, ensuring product durability and efficiency





      Learn more>>

      GOVERNANCE

      Streamline product lifecycle management (PLM) with ENOVIA, offering centralized data storage, secure access control and workflow automation, ensuring efficient engineering collaboration across teams.



      Learn more>>

      MANUFACTURE

      Optimize manufacturing operations with DELMIA, utilizing digital twin technology, virtual production planning, and robotics integration to improve efficiency, reduce costs and enhance factory performance.





      Learn more>>

      ACADEMIA CLIENTS

      What’s New in SOLIDWORKS 2025?

      Stay ahead with the latest SOLIDWORKS 2025 enhancements, designed to improve design efficiency, collaboration, and performance. As the best authorized SOLIDWORKS reseller in Chennai, Coimbatore and Kolhapur. SIMTEK ensures you get access to the most advanced tools for 3D design, simulation and manufacturing.

      ✅ Enhanced 3D Modeling – Faster and more intuitive CAD modeling capabilities, including improved sketching, parametric design and assembly performance.

      ✅ Advanced Simulation Tools – SOLIDWORKS Simulation 2025 now supports more complex stress, thermal and motion studies, ensuring better product validation and reliability.

      ✅ Cloud-Based Collaboration – 3DEXPERIENCE integration offers real-time data sharing, improved PDM workflows and enhanced version control, streamlining team collaboration.

      ✅ Optimized Manufacturing Solutions – SOLIDWORKS CAM & MBD 2025 bring smarter automation for machining, inspection and 3D printing, improving production efficiency.

      ✅ Better Performance & UI Improvements – The latest update ensures faster processing speeds, a modernized interface and improved usability, boosting overall productivity.

      SERVICES WE PROVIDE ALONG WITH LICENSE

      SOLIDWORKS SUPPORT

      Get 24/7 SOLIDWORKS technical support from certified experts in Chennai, Coimbatore and Kolhapur. We offer onsite, remote and phone support to resolve issues quickly, ensuring uninterrupted design, simulation and manufacturing workflows.

      Learn more>>

      SOLIDWORKS CERTIFICATION

      Enhance your career with official SOLIDWORKS certifications, including CSWA, CSWP and CSWE. Our certified training centers provide hands-on courses for engineers, students and professionals to master SOLIDWORKS design and simulation.

      Learn more>>

      SOLIDWORKS SUBSCRIPTION

      Stay updated with the latest SOLIDWORKS features, security updates and exclusive resources. Our affordable SOLIDWORKS subscription services include priority support, software enhancements and cloud collaboration tools to streamline workflows.

      Learn more>>

      TRAINING LICENSE

       Learn from experts with hands-on SOLIDWORKS training courses, covering design, simulation, PDM, and electrical solutions, tailored for engineers, designers, and manufacturers.





      Learn more>>

      See Why Businesses Trust SIMTEK – Real SOLIDWORKS Success Stories!

      Hear from businesses, engineers and manufacturers in Chennai, Coimbatore, and Kolhapur who have transformed their workflows with genuine SOLIDWORKS licenses, certified training and expert technical support. See how our best-in-class SOLIDWORKS reseller services, including affordable SOLIDWORKS pricing, flexible licensing and subscription plans, have helped companies achieve design efficiency, innovation and productivity gains.

      RECENT BLOGS

      March 28, 2025 0 comments

      Authorized 3DEXPERIENCE SOLIDWORKS Reseller in India

      SIM TECHNOLOGIES is an Authorized SOLIDWORKS & 3DEXPERIENCE Works reseller and engineering solution provider in Chennai, Coimbatore and Kolhapur. We are also an authorized SOLIDWORKS Training and SOLIDWORKS Certification center in Tamilnadu. We support our customers with SOLIDWORKS Technical Training & SOLIDWORKS Webinars at various locations in Tamilnadu.

      Everything we do is focused on close collaboration and engagement with our consumers. SIMTEK delivers best-in-class design solutions that are easy to use, administer, and interface with other platforms, with over 25 years of expertise and 1000+ customers in high tech, medical, machine design, energy and other industries. We are also proud to serve academic institutions as the Regional champion for colleges, universities and schools.

      As an electric beehive of ideas, we also deliver strong and transformative solutions in design, simulation, product data management, manufacturing, reverse engineering, finite element analysis, value engineering and CAD modifications as a best SOLIDWORKS Reseller in India.

        Best Authorized SOLIDWORKS Reseller in Chennai, Coimbatore & Kolhapur

        Get affordable SOLIDWORKS software pricing and deals in Chennai with certified training & technical support

        1000+ Clients

        Trusted by leading businesses for reliable SOLIDWORKS solutions.

        3 Office Locations

        Serving businesses across Tamil Nadu & Kolhapur with dedicated SOLIDWORKS support.

        100+ Industry Awards

        Honored for outstanding SOLIDWORKS expertise, service and innovation.

        25+ Years Experience

        Serving businesses with expert SOLIDWORKS solutions.

        Schedule Demo
        Request Quote

        Why 1000+ Customers Choose SIMTEK?

        SIMTEK is the best authorized SOLIDWORKS reseller in Chennai, Coimbatore and Kolhapur, trusted by 1000+ businesses, engineers and manufacturers for genuine SOLIDWORKS licenses, expert training and 24/7 technical support. We offer affordable SOLIDWORKS pricing, flexible licensing options and exclusive subscription deals, ensuring seamless CAD, simulation and PDM workflows.

        As a top-rated SOLIDWORKS reseller, our certified training centers provide industry-recognized certifications and hands-on expertise in SOLIDWORKS design, simulation and manufacturing solutions. With 25+ years of experience, we specialize in SOLIDWORKS implementation, consultation and automation, helping engineering, manufacturing, automotive and aerospace industries boost design efficiency and innovation.

        Our commitment to quality, performance and customer satisfaction makes us the leading SOLIDWORKS reseller for businesses looking for expert support and cutting-edge solutions.

        SOLIDWORKS is the most popular choice for designers and manufacturers, offering advanced features and enhancements for Electromechanical 3D Design, Simulation and Product Data Management software solutions. As an authorized SOLIDWORKS reseller in Chennai, we provide industry-leading SOLIDWORKS 3D CAD software to help companies accelerate product development, lower manufacturing costs, and ensure product quality and reliability.

        Looking to buy SOLIDWORKS in Chennai or explore the best SOLIDWORKS license price in Chennai? SIMTEK provides the most competitive pricing on SOLIDWORKS Standard, Professional, Premium, PDM, Electrical, CAM and Simulation. As the top SOLIDWORKS reseller in Chennai, we ensure expert support and tailored solutions for your business.

        Schedule a demonstration or request a quote today to get the best SOLIDWORKS deals from SIMTEK – the best SOLIDWORKS reseller in Chennai!

        SOLIDWORKS

        OUR CLIENTS

        OUR SERVICES

        CAD SERVICES

        As the best authorized SOLIDWORKS reseller in Chennai and Coimbatore, we provide SOLIDWORKS 3D CAD solutions for product modeling, drafting and assembly design. Our CAD services help engineering firms and manufacturers streamline design-to-production workflows, automate repetitive tasks and improve collaboration.

        Learn more>>

        CAE SERVICES

         With SOLIDWORKS Simulation, we offer structural analysis, thermal simulation and motion studies to enhance product durability and efficiency. Our affordable SOLIDWORKS software pricing in Chennai and Coimbatore ensures businesses get cost-effective solutions for stress testing and design validation.

        Learn more>>

        REVERSE ENGINEERING

        We use high-precision 3D scanning to convert physical parts into detailed 3D CAD models, ideal for legacy part recreation, design modifications and industrial upgrades. Our expertise helps manufacturing companies in Chennai and Coimbatore optimize production.

        Learn more>>

        3D PRINTERS & 3D SCANNERS

        AGet top-rated 3D printers and scanners for rapid prototyping, product validation, and quality inspection. We offer affordable SOLIDWORKS subscription services with flexible licensing for seamless integration

        Learn more>>

        SOLIDWORKS Portfolio

        As the best authorized SOLIDWORKS reseller in Chennai, Coimbatore and Kolhapur. SIMTEK provides a comprehensive SOLIDWORKS solution to optimize design, simulation, manufacturing and data management for businesses and engineering firms.

         DESIGN

        Leverage SOLIDWORKS 3D CAD software for precise product modeling, assembly design and drafting. Our affordable SOLIDWORKS pricing in Chennai, Coimbatore and Kolhapur ensures businesses get the best CAD solutions for product development.

        Learn more>>

        SIMULATION

        With SOLIDWORKS Simulation, conduct stress analysis, thermal evaluation, and motion studies to improve product reliability and cost-effectiveness. Ideal for engineering firms and manufacturers in Chennai, Coimbatore and Kolhapur.



        Learn more>>

        GOVERNANCE

        Manage engineering data, PDM workflows and product lifecycle using SOLIDWORKS PDM and 3DEXPERIENCE solutions. Get seamless collaboration, version control and secure data management for better project execution.



        Learn more>>

        MANUFACTURE

        Optimize CNC machining, production and quality control with SOLIDWORKS CAM, MBD and Inspection tools. Our SOLIDWORKS implementation and consultation services in Chennai, Coimbatore and Kolhapur help industries achieve efficient manufacturing workflows.

        Learn more>>

        MARKETING

        Create high-quality 3D renderings, animations and interactive product experiences with SOLIDWORKS Visualize and Composer. Our certified SOLIDWORKS training centers in Chennai & Coimbatore ensure businesses maximize their marketing and sales potential.

        Learn more>>

        3DEXPERIENCE Portfolio

        As the Trusted SOLIDWORKS reseller in Chennai, Coimbatore and Kolhapur, SIMTEK offers 3DEXPERIENCE solutions that integrate design, simulation, data management and smart manufacturing to enhance product development and business efficiency.

         DESIGN

        3DEXPERIENCE SOLIDWORKS provides a cloud-based 3D CAD environment with seamless collaboration, real-time data access, and integrated project management, helping teams accelerate product design and innovation.

        Learn more>>

        SIMULIA

        Perform high-end simulations with SIMULIA, enabling engineers to analyze stress, heat transfer, fluid dynamics and complex physics-based scenarios, ensuring product durability and efficiency.



        Learn more>>

        ENOVIA

        Streamline product lifecycle management (PLM) with ENOVIA, offering centralized data storage, secure access control and workflow automation, ensuring efficient engineering collaboration across teams.

        Learn more>>

        DELMIA

        Optimize manufacturing operations with DELMIA, utilizing digital twin technology, virtual production planning, and robotics integration to improve efficiency, reduce costs and enhance factory performance.



        Learn more>>

        ACADEMIA CLIENTS

        What’s New in SOLIDWORKS 2025?

        Stay ahead with the latest SOLIDWORKS 2025 enhancements, designed to improve design efficiency, collaboration, and performance. As the best authorized SOLIDWORKS reseller in Chennai, Coimbatore and Kolhapur. SIMTEK ensures you get access to the most advanced tools for 3D design, simulation and manufacturing.

        ✅ Enhanced 3D Modeling – Faster and more intuitive CAD modeling capabilities, including improved sketching, parametric design and assembly performance.

        ✅ Advanced Simulation Tools – SOLIDWORKS Simulation 2025 now supports more complex stress, thermal and motion studies, ensuring better product validation and reliability.

        ✅ Cloud-Based Collaboration – 3DEXPERIENCE integration offers real-time data sharing, improved PDM workflows and enhanced version control, streamlining team collaboration.

        ✅ Optimized Manufacturing Solutions – SOLIDWORKS CAM & MBD 2025 bring smarter automation for machining, inspection and 3D printing, improving production efficiency.

        ✅ Better Performance & UI Improvements – The latest update ensures faster processing speeds, a modernized interface and improved usability, boosting overall productivity.

        SERVICES WE PROVIDE ALONG WITH LICENSE

        SOLIDWORKS SUPPORT

        Get 24/7 SOLIDWORKS technical support from certified experts in Chennai, Coimbatore and Kolhapur. We offer onsite, remote and phone support to resolve issues quickly, ensuring uninterrupted design, simulation and manufacturing workflows.

        Learn more>>

        SOLIDWORKS CERTIFICATION

        Enhance your career with official SOLIDWORKS certifications, including CSWA, CSWP and CSWE. Our certified training centers provide hands-on courses for engineers, students and professionals to master SOLIDWORKS design and simulation.

        Learn more>>

        SOLIDWORKS SUBSCRIPTION

        Stay updated with the latest SOLIDWORKS features, security updates and exclusive resources. Our affordable SOLIDWORKS subscription services include priority support, software enhancements and cloud collaboration tools to streamline workflows.

        Learn more>>

        SOLIDWORKS LICENSE

         Learn from experts with hands-on SOLIDWORKS training courses, covering design, simulation, PDM, and electrical solutions, tailored for engineers, designers, and manufacturers.



        Learn more>>

        See Why Businesses Trust SIMTEK – Real SOLIDWORKS Success Stories!

        Hear from businesses, engineers and manufacturers in Chennai, Coimbatore, and Kolhapur who have transformed their workflows with genuine SOLIDWORKS licenses, certified training and expert technical support. See how our best-in-class SOLIDWORKS reseller services, including affordable SOLIDWORKS pricing, flexible licensing and subscription plans, have helped companies achieve design efficiency, innovation and productivity gains.

        September 17, 2024 0 comments

        SOLIDWORKS ULTIMATE

        SOLIDWORKS ULTIMATE

        The ultimate end-to-end product development solution from SOLIDWORKS

        SOLIDWORKS ULTIMATE

        The ultimate end-to-end product development solution from SOLIDWORKS

        SOLIDWORKS Ultimate offers designers and engineers a comprehensive solution that drives every aspect of product development. Moreover, it provides more than just great design tools—it connects every phase of your development process, from simulation to manufacturing, marketing, and project management. As a result, SOLIDWORKS Ultimate accelerates workflows and breaks down silos.

        Whether you’re a startup or a growing enterprise, SOLIDWORKS Ultimate equips you with a powerful suite of tools to transform ideas into finished products. Furthermore, it keeps your data securely connected in the cloud, ensuring seamless collaboration.

        Get a Quote
        Get a Demo

        SOLIDWORKS Innovation Day 2024

        SolidWorks Innovation Day 2024 is a premier event where design professionals, engineers, and innovators gather to explore the latest advancements in 3D CAD technology. This year’s event focuses on groundbreaking updates in SOLIDWORKS software, including new tools for streamlining workflows, enhancing collaboration, and boosting design efficiency. Attendees can expect immersive demonstrations, expert-led sessions, and hands-on experiences with cutting-edge features, empowering them to stay ahead in the fast-evolving world of product design and manufacturing. SolidWorks Innovation Day 2024 promises to be a celebration of creativity, pushing the boundaries of what's possible in engineering and design.

        REGISTER HERE TO JOIN THE INNOVATION DAY 2024

        solidworks ultimate

        SOLIDWORKS Ultimate

        What’s Included With SOLIDWORKS Ultimate

        Design

        Design in SOLIDWORKS Ultimate combines advanced 3D modeling capabilities with powerful simulation tools, enabling engineers and designers to create intricate designs with precision.

        With features like parametric modeling, sheet metal design, and surface modeling, users can develop complex assemblies efficiently. The integrated simulation tools allow for real-time analysis, ensuring designs meet performance standards while minimizing material costs.

        SOLIDWORKS Ultimate empowers teams to innovate faster, collaborate seamlessly, and bring products to market with confidence.

        Simulate

        Simulation in SOLIDWORKS Ultimate enhances design validation by allowing engineers to analyze the performance of their models under real-world conditions. With tools for structural, thermal, fluid flow, and motion analysis, users can identify potential issues early in the design process.

        This comprehensive simulation suite helps optimize designs for strength, durability, and efficiency, reducing the need for costly physical prototypes and accelerating time to market. SOLIDWORKS Ultimate empowers teams to innovate confidently, ensuring products meet rigorous performance standards.

        Collaborate

        Collaboration in SOLIDWORKS Ultimate streamlines teamwork by enabling seamless sharing and integration of designs across different departments. With features like SOLIDWORKS PDM (Product Data Management), teams can manage revisions, track changes, and maintain version control effortlessly.

        The cloud-based capabilities facilitate real-time collaboration, allowing multiple users to work on the same project from various locations.

        This interconnected environment enhances communication, reduces errors, and ensures everyone is aligned, ultimately driving innovation and improving project outcomes.

        Manage

        Management in SOLIDWORKS Ultimate focuses on optimizing the design workflow through efficient data organization and project oversight.

        With SOLIDWORKS PDM (Product Data Management), users can centralize their design files, streamline version control, and automate processes to enhance productivity.

        This powerful management system enables teams to track project progress, ensure compliance, and facilitate collaboration across departments.

        By improving data accessibility and security, SOLIDWORKS Ultimate empowers organizations to manage their design projects effectively, reducing time to market and fostering innovation.

        Market

        Marketing in SOLIDWORKS Ultimate is enhanced by its ability to streamline product design and development processes, allowing companies to bring innovative solutions to market faster.

        With robust visualization tools, users can create stunning renderings and animations that effectively showcase their products, capturing customer interest and enhancing promotional efforts.

        Additionally, the integration of simulation and testing features helps ensure that products meet market demands and performance standards before launch. By optimizing the design-to-market pipeline, SOLIDWORKS Ultimate enables businesses to respond swiftly to market trends and customer needs.

        Manufacture

        Manufacturing in SOLIDWORKS Ultimate is streamlined through advanced tools that facilitate the transition from design to production.

        With features such as detailed drawings, assembly instructions, and manufacturing simulation, users can optimize designs for manufacturability and reduce production costs. The software also supports additive and subtractive manufacturing techniques, enabling engineers to prepare designs for 3D printing or traditional machining.

        By integrating manufacturing considerations early in the design process, SOLIDWORKS Ultimate helps companies enhance efficiency, minimize errors, and ensure that products are ready for market faster.

        Why Choose SOLIDWORKS Ultimate?

        Scalable Solutions for Any Business

        SOLIDWORKS Ultimate grows with your business. Whether you're in the early stages or scaling up, it provides the tools to meet today's demands and tackle tomorrow’s challenges. From ideation to manufacturing, every aspect of product development is covered.

        Single Source of Truth

        Say goodbye to data silos. With SOLIDWORKS Ultimate, all your tools connect to a single, cloud-based source of truth. This ensures accuracy, eliminates data duplication, and enables smooth collaboration with trusted stakeholders—all while keeping your data secure and easily accessible.

        Set Up for Success

        Expanding beyond design into new disciplines can be challenging. SOLIDWORKS Ultimate makes it easy with access to thousands of training resources and lessons that help you quickly master new tools and elevate your skills.

        Get a Quote

        FREQUENTLY ASKED QUESTIONS

        What is SOLIDWORKS Ultimate?

        SOLIDWORKS Ultimate is an all-in-one product development solution that goes beyond design to include simulation, manufacturing, marketing, and project management tools. It integrates with the 3DEXPERIENCE platform, allowing seamless collaboration and data management in the cloud.

        How does SOLIDWORKS Ultimate differ from SOLIDWORKS Premium?

        While SOLIDWORKS Premium focuses on advanced 3D CAD design and simulation tools, SOLIDWORKS Ultimate includes additional features such as cloud-based collaboration, lifecycle management, marketing content creation, and advanced manufacturing solutions. It offers a complete product development platform from ideation to manufacturing.

        Can SOLIDWORKS Ultimate be used by small teams or startups?

        Yes, SOLIDWORKS Ultimate is scalable and designed to support businesses of all sizes, from startups to large enterprises. Its cloud-based tools make it accessible and flexible, allowing small teams to collaborate efficiently and grow their capabilities over time.

        August 31, 2024 0 comments

        Newsletter

        SIMTEK India

        phone-icon marketing@simtek.in |  phone-icon +91 8754447021

        simtek-solidworks

        Stay Ahead in the World of DESIGN Technology

        Why Subscribe to Our Newsletter?

        1. Stay Informed: Receive exclusive updates on the latest in 3D printing, scanning, and CAD solutions. Be the first to know about new technologies, industry trends, and innovative applications.

        2. Solve Problems Faster: Get access to expert tips, how-to guides, and case studies that address common pain points and help you tackle complex projects with ease.

        3. Enhance Your Skills: Gain valuable knowledge through in-depth articles, tutorials, and training opportunities designed to boost your expertise and keep you ahead of the competition.

        4. Get the Inside Scoop: Be the first to hear about upcoming webinars, events, and special offers tailored to your interests and needs.

        5. Join a Community of Innovators: Connect with like-minded professionals and industry leaders who share your passion for technological advancement and excellence.

        Don’t Miss Out! Join our community of forward-thinking professionals and stay at the forefront of 3D technology. Subscribe to our newsletter today and be empowered with the knowledge and tools you need to excel.

        Unlock the Latest Insights and Innovations with SIM Technologies

        Unlock exclusive updates and tips—subscribe to our newsletter now!

          What is 3DEXPERIENCE Works and Why is it Important?

          The 3DEXPERIENCE Works is an integrated platform based on the cloud. It facilitates collaborative working and brings all aspects of the development together. By bringing different apps together, all business tasks can be accomplished. This 3DEXPERIENCE Works suite helps to complement the desktop applications and promotes anytime, anywhere working.

          Get a Demo
          Get a Quote

          HOW DOES 3DEXPERIENCE SOLIDWORKS PLATFORM WORK?

          STEP 1

          3DEXPERIENCE SOLIDWORKS platform

          CHOOSE CATEGORY

          The 3DEXPERIENCE SOLIDWORKS platform includes four main categories; Design (powered by SOLIDWORKS), Simulate (powered by SIMULIA), Manufacturing (powered by DELMIA), and Manage (powered by ENOVIA). You can customize your 3DEXPERIENCE SOLIDWORKS platform based on the capabilities you need.

          STEP 2

          3DEXPERIENCE SOLIDWORKS - Define roles

          DEFINE ROLES

          Over 500 different roles mean that you are empowered to collaborate with anyone in your organization and across your ecosystem. Unleash the potential of teamwork, yet offer a customized 3DEXPERIENCE SOLIDWORKS dashboard based on unique user needs.

          STEP 3

          Utilize 3DEXPERIENCE SOLIDWORKS apps

          UTILIZE APPS

          Category-specific apps are available and this means that anyone using the 3DEXPERIENCE SOLIDWORKS has something to offer. Go on to collaborate extensively with all stakeholders including but not limited to your teams, manufacturers, consultants, etc.

          SELECT A CATEGORY

          Begin your 3DEXPERIENCE SOLIDWORKS journey here by selecting which stage of product development you need applications for.

          Start your 3DEXPERIENCE path here if you need intutive apps to design products, parts and assemblies.

          LEARN MORE

          DESIGN

          Have a designed product that needs simulation analysis and testing? Start your 3DEXPERIENCE path here.

          LEARN MORE

          SIMULATE

          Ready to begin manufacturing your product? Utilize DELMIAWORKS specifically designed for manufacturing.

          LEARN MORE

          MANUFACTURE

          Need tools to help plan and manage your development? 3DEXPERIENCE apps powered by ENOVIA can assist you.

          LEARN MORE

          MANAGE
          August 13, 2024 0 comments

          Swap to SOLIDWORKS

          Are you still working on outdated or complex CAD software?

          It’s time to upgrade your design process and maximize ROI with SOLIDWORKS — the world’s leading 3D CAD platform trusted by millions of engineers and product designers globally.

          Whether you're using AutoCAD, PTC Creo, CATIA, Siemens NX or any other 3D tool — this is your golden opportunity to migrate effortlessly to SOLIDWORKS and gain unmatched benefits.

          How Will It Work?

          At SIM Technologies (SIMTEK), we’ve helped thousands of design teams migrate to SOLIDWORKS seamlessly without losing productivity or design data. Here’s how the transition unfolds:

          • FREE Migration Consultation
            We'll evaluate your current CAD tools, team setup and project complexity.
          • Custom Migration Plan
            From software setup to license management everything is tailored to your needs.
          • Hands-on Implementation Support
            Our certified engineers will ensure hassle-free migration with zero disruption.
          • Team Training + Onboarding
            We train your team to become SOLIDWORKS experts quickly and confidently.

          Request for Quote

            Why Should You Migrate to SOLIDWORKS?

            When it comes to delivering engineering excellence, SOLIDWORKS stands unmatched. Here’s why top design teams around the world are switching:

            User-Friendly Interface

            Even first-time users adapt quickly with SOLIDWORKS’ intuitive, drag-and-drop UI

            Future-Proof Platform

            Stay ahead with constant innovation, updates, and cloud-connected 3DEXPERIENCE compatibility.

            Robust PLM Integration

            Seamlessly integrates with leading PLM systems for efficient cross-team collaboration.

            Powerful Simulation & Visualization

            Get built-in tools like Simulation, Flow, Plastics & Visualize for better product design and analysis.

            Huge Global Community

            Join a thriving ecosystem of designers, engineers, tutorials, and global support forums.

            OUR CLIENTS

            ACADEMIA CLIENTS

            What’s New in SOLIDWORKS 2025?

            Stay ahead with the latest SOLIDWORKS 2025 enhancements, designed to improve design efficiency, collaboration, and performance. As the best authorized SOLIDWORKS reseller in Chennai, Coimbatore and Kolhapur. SIMTEK ensures you get access to the most advanced tools for 3D design, simulation and manufacturing.

            ✅ Enhanced 3D Modeling – Faster and more intuitive CAD modeling capabilities, including improved sketching, parametric design and assembly performance.

            ✅ Advanced Simulation Tools – SOLIDWORKS Simulation 2025 now supports more complex stress, thermal and motion studies, ensuring better product validation and reliability.

            ✅ Cloud-Based Collaboration – 3DEXPERIENCE integration offers real-time data sharing, improved PDM workflows and enhanced version control, streamlining team collaboration.

            ✅ Optimized Manufacturing Solutions – SOLIDWORKS CAM & MBD 2025 bring smarter automation for machining, inspection and 3D printing, improving production efficiency.

            ✅ Better Performance & UI Improvements – The latest update ensures faster processing speeds, a modernized interface and improved usability, boosting overall productivity.

            See Why Businesses Trust SIMTEK – Real SOLIDWORKS Success Stories!

            Hear from businesses, engineers and manufacturers in Chennai, Coimbatore, and Kolhapur who have transformed their workflows with genuine SOLIDWORKS licenses, certified training and expert technical support. See how our best-in-class SOLIDWORKS reseller services, including affordable SOLIDWORKS pricing, flexible licensing and subscription plans, have helped companies achieve design efficiency, innovation and productivity gains.

            August 12, 2024 0 comments

            SOLIDWORKS TRAINING

            ACADEMIC CERTIFICATION

            Academic Certification

            In today's highly competitive job market, where every advantage counts, CAD professionals must equip themselves with the best tools and credentials to stand out. The SOLIDWORKS Certification Program offers your students a tangible and recognized advantage, giving them a proven edge that sets them apart from their peers and enhances their career prospects.

            Students may take these exams for free if their school is a SOLIDWORKS Academic Certification Provider and on subscription.  Minimum license requirements apply and vary as per the region.



            CSWA-Mechanical Design - Academic Version

            CSWA - Academic certification is intended for a student who is well-versed in both basic knowledge of engineering fundamentals and industry practices, along with SOLIDWORKS CAD software and its methodologies and simulation principles.

            CSWA – Electrical

            The Certified SOLIDWORKS Associate — Electrical (CSWA–E) certification shows that you have successfully demonstrated an understanding of the principles of SOLIDWORKS Electrical functionality and Electrical Engineering principles.

            CSWA - Additive Manufacturing

            A Certified Additive Manufacturing Associate is someone who possesses the basic knowledge of today’s 3D printing market.

            CSWA - Simulation

            The Certified SOLIDWORKS Associate - Simulation (CSWA-Simulation) certification indicates a foundation in and apprentice knowledge of demonstrating an understanding of the principles of stress analysis and the Finite Element Method (FEM).

            CSWP-Mechanical Design - Academic Version

            Certified SOLIDWORKS Professional - Academic (CSWP - Academic) certification is intended for a student with a minimum of 1 to 2 years of SOLIDWORKS experience and advanced knowledge of engineering practices.

            CSWP- CAM

            The completion of the Certified SOLIDWORKS Professional CAM (CSWP-CAM) exam shows that you have successfully demonstrated your ability to use SOLIDWORKS CAM functionality and tools.

            CSWP - Simulation

            The Certified SOLIDWORKS Professional - Simulation (CSWP-Simulation) exam tests your understanding of SOLIDWORKS Simulation tools and simulation in general.

            CSWP - MBD

            The completion of the Certified SOLIDWORKS Professional Model-Based Design (CSWP-MBD) exam shows that you have successfully demonstrated your ability to use SOLIDWORKS MBD functionality and tools.

            CSWPA - Drawing Tools

            The completion of the Certified SOLIDWORKS Professional Advanced Drawing Tools (CSWPA-DT) exam proves that you have successfully demonstrated your ability to use the tools found in the SOLIDWORKS Drawing environment.

            CSWPA - Mold Making

            The completion of the Certified SOLIDWORKS Professional Mold Making (CSWPA-MM) exam shows that you have successfully demonstrated your ability to use SOLIDWORKS Mold Tools functionality with Mold Making Industry knowledge.

            CSWPA - Sheet Metal

            The completion of the Certified SOLIDWORKS Professional Advanced Sheet Metal (CSWPA-SM) exam shows that you have successfully demonstrated your ability to use SOLIDWORKS Sheet Metal tools.

            CSWPA - Surfacing

            The completion of the Certified SOLIDWORKS Professional Advanced Surfacing (CSWPA-SU) exam shows that you have successfully demonstrated your ability to use SOLIDWORKS Advanced Surfacing tools.

            CSWPA - Weldments

            The completion of the Certified SOLIDWORKS Professional Advanced Weldments (CSWPA-WD) exam proves that you have successfully demonstrated your ability to use the SOLIDWORKS tools for Weldments.

            3DEXPERIENCE - Collaborative Business Innovator

            The completion of the 3DEXPERIENCE - Collaborative Business Innovator exam shows that you have successfully demonstrated your basic knowledge of the 3DEXPERIENCE Platform.

            3DEXPERIENCE – Collaborative Industry Innovator

            The completion of the 3DEXPERIENCE – Collaborative Industry Innovator exam shows that you have successfully demonstrated your understanding of data management tools available on the 3DEXPERIENCE Platform

            3DEXPERIENCE – 3D Creator

            The completion of the 3DEXPERIENCE – 3D Creator exam shows that you have successfully demonstrated your basic knowledge of the browser-based 3D Design Role.

            3DEXPERIENCE – 3D Sculptor

            The completion of the 3DEXPERIENCE – 3DSculptor exam shows that you have successfully demonstrated your basic knowledge of the browser-based 3D Sculptor role.

            ADDITIONAL TEACHER/INSTRUCTOR CERTIFICATION

            Accredited Educator Certification

            Educators play a vital role in developing the next generation of engineering and design innovators. The SOLIDWORKS Accredited Educator certification provides educators the professional development credential to demonstrate technical proficiency and skill in the classroom.

            TECE Exam

            Technology Educator Competency Exam (TECE) is intended for educators that teach using SOLIDWORKS software in a classroom setting. The TECE demonstrates technical proficiency in classroom instruction for 3D CAD, simulation, and sustainable design.
            June 13, 2024 0 comments

            INTEC 2024, A Convergence of Innovation and Industry with SIMTEK

            SIMTEK Showcase at INTEC 2024

            INTEC, the International Machine Tools & Industrial Trade Fair, has been a beacon of industrial advancement and a hub for business opportunities for two decades. As it reached its 20th edition, INTEC 2024 stands as a testament to the fair’s enduring legacy and its pivotal role in shaping the future of manufacturing and engineering.

            At INTEC 2024, SIM Technologies Private Limited took center stage with an impressive display of their latest engineering solutions and services. Their participation was not just about exhibiting products; it was about demonstrating their role as a catalyst for innovation in the engineering sector.

            INTEC 2024, A Convergence of Innovation and Industry with SIMTEK

            A Display of Pioneering Solutions

            SIM Technologies’ stall was a microcosm of the future of engineering design and manufacturing. They showcased the newest versions of SOLIDWORKS & 3DEXPERIENCE SOLIDWORKS, offering visitors a hands-on experience with the software that is driving the industry forward. The demonstrations highlighted the software’s capabilities in 3D design, simulation, and product data management, emphasizing how these tools can optimize the entire product development process.

            Key Themes and Innovations at INTEC 2024

            As the industrial world converges at INTEC 2024, the air is thick with anticipation for the key themes and innovations that will define the future of manufacturing. This year, the event was poised to unveil a series of groundbreaking advancements that promise to elevate the industry to new heights.

            The Digital Transformation

             Industry 4.0 and Beyond The buzzword ‘Industry 4.0’ finds concrete expression at INTEC 2024, where digital transformation takes center stage. Unconventional technologies such as AI-driven analytics, IoT-enabled devices, and smart automation systems are on display, showcasing how data and connectivity are reshaping the industrial landscape.

            Additive Manufacturing

             Crafting the Future 3D printing and additive manufacturing technologies are set to revolutionize how we create products. INTEC 2024 highlighted the latest advancements in this field, demonstrating how complex components can now be crafted with precision and speed, opening up possibilities for customization and innovation.

            Strengthening Industry Presence

            INTEC 2024 served as a platform for SIM Technologies to reinforce its presence in the engineering solutions sector. The event allowed them to showcase their strengths, particularly in the areas of CAD solutions and SOLIDWORKS expertise. Their interactive demonstrations and comprehensive product presentations left a lasting impression on the attendees, solidifying their reputation as a leader in the field.

            A Green Gesture

             Seed Balls Giveaway In a unique and thoughtful initiative, SIM Technologies provided visitors with a freebie that carried a message of sustainability – seed balls. These seed balls, given away to attendees, symbolize the company’s commitment to environmental consciousness and the greening of our planet. It was a small but powerful gesture that resonated with the event’s attendees, reflecting the company’s dedication to eco-friendly practices.

            Setting the Stage for Future Innovations

            The feedback and discussions at INTEC 2024 have set the stage for SIM Technologies to plan and develop future innovations. The company’s focus on sustainable and efficient solutions was well-received, and they are poised to continue this trajectory, developing products and services that not only meet but anticipate the future needs of the industry.

            October 22, 2021 0 comments

            DraftSight

            DRAFTSIGHT

            2D CAD Drafting and 3D Design Software

            What is DraftSight?

            Draftsight is versatile software offering 2D computer-aided drafting for all engineering services including, mechanical, manufacturing, electrical and architectural, among others. It can be used for both 2D and 3D drawings and is capable of handling projects of any complexity in an elegant and easy fashion.

            Get a Demo
            Get a Quote

            Integration with SOLIDWORKS Applications

            • Draftsight integrates with SOLIDWORKS PDM Professional, thereby helping assure data security and version control.
            • One can easily work on SOLIDWORKS by just copying and pasting from Draftsight. Thus there is no complex migration, data, or format changes involved and no loss of information.

            SOLIDWORKS Electrical Integration

            Users with SOLIDWORKS Electrical integration can simply add, edit, and modify symbols with easy actions and stored in the SOLIDWORKS library as well. Further, Draftsight offers excellent documentation capabilities for marking up and viewing electrical projects. Thus platform compatibility offers increased scope and ease of use.

            TOOLS

            3DEXPERIENCE MARKETPLACE

            By collaborating with the 3DEPERIENCE Marketplace, you have access to a wider range of projects, users, and service providers. Designing and passing the same for testing, prototyping, and production is simple.

            HomeByMe

            Architects are now empowered to take full advantage of the Draftsight and SOLIDWORKS suite. HomeByMe is a cloud-based 3D architectural ‘home’ design tool by Dassault Systems.

            Toolbox (Professional, Premium, and Enterprise)

            Different design aspects can be automated suitably based on national and international standards and this feature is available in different flavours depending on the user's need.

            Image Tracer (Professional, Premium, and Enterprise)

            The DraftSight Image Tracer is an easy-to-use and intuitive tool to help convert any raster and non CAD images into editable drawings in 2D.

            LISP Files support (*.lsp, *.mnl, and *.dll)

            Yes. Macros can be created and programming languages used in Draftsight! The DraftSight API can allow users to write commands. Thus any repetitive tasks and other functions can be automated.

            G-Code Generator (Professional, Premium, and Enterprise)

            Drawings can now be converted into code easily by the C-code generator. This can be used on CNC machines, among others.

            Draw Compare (Professional, Premium, and Enterprise)

            Are you stuck with 2 drawings that look similar? Are you struggling with versions and lack the ability to find out differences? Draw Compare solves all your challenges by helping compare drawings and documents.

            DRAFTSIGHT PACKAGES

            The advanced 2D CAD drafting solution with powerful, time-saving functionalities and an API to help bring your designs to life quickly and easily.

            Ideal for companies, individuals, and designers.

            The robust 2D drafting and 3D design experience with full 3D capabilities and constraints features to help meet all of your drafting, modeling, prototyping, manufacturing, laser cutting and 3D printing needs..

            Created for individuals, designers, companies, manufacturers and makers.

            The comprehensive 2D drafting and 3D design solution to meet any drafting, modeling, prototyping, manufacturing, laser cutting and 3D printing requirement. Includes full technical support, deployment and network licensing to enable concurrent usage.

            Designed for large organizations with many users or multiple sites.

            FREQUENTLY ASKED QUESTIONS

            What are the advantage(s) of using DraftSight over other 2D CAD packages?

            It has a familiar user interface, short learning curve and easily transitions files and workflow from your current legacy 2D data.

            How can I access Technical Support for DraftSight?

            Options will vary based on the product level.  Contact SIMTEK  directly to help.

            What file formats does DraftSight support?

            Draftsight supports both DWG and DXF and both of these formats are also compatible with SOLIDWORKS.
            July 5, 2021 0 comments

            SOLIDWORKS Certifications

            ACADEMIC CERTIFICATION

            In today’s competitive job market, CAD professionals and students need the right skills and credentials to stand out. The SOLIDWORKS Certification Program provides a tangible and recognized advantage, giving students a proven edge in their careers. As the best authorised SOLIDWORKS reseller in Chennai, Coimbatore, and Kolhapur, SIMTEK supports academic institutions in integrating SOLIDWORKS certification into their curriculum.

            Institutions that are SOLIDWORKS Academic Certification Providers and have an active subscription can offer students free certification exams, ensuring they graduate with industry-recognized qualifications. With SIMTEK’s expertise in training, implementation, and support, schools and colleges can equip students with the best mechanical design software and prepare them for real-world success.

            CSWA-Mechanical Design - Academic Version

            CSWA - Mechanical Design – Academic Version is intended for a student who is well-versed in both basic knowledge of engineering fundamentals and industry practices, along with SOLIDWORKS CAD software and its methodologies and simulation principles

            CSWA – Electrical

            The Certified SOLIDWORKS Associate — Electrical (CSWA–E) certification shows that you have successfully demonstrated an understanding of the principles text-align: justifyof SOLIDWORKS Electrical functionality and Electrical Engineering principles.

            CSWA - Additive Manufacturing

            A Certified Additive Manufacturing Associate is someone who possesses basic knowledge of today’s 3D printing market, a key aspect of SOLIDWORKS for hobbyists

            CSWA - Simulation

            The Certified SOLIDWORKS Associate – Simulation (CSWA-Simulation) certification indicates a foundation in and apprentice knowledge of stress analysis and Finite Element Method (FEM), important for SOLIDWORKS surface modeling

            CSWP-Mechanical Design - Academic Version

            Certified SOLIDWORKS Professional – Academic (CSWP – Academic) certification is intended for a student with 1 to 2 years of SOLIDWORKS experience and advanced knowledge of engineering practices.

            CSWP- CAM

            The completion of the Certified SOLIDWORKS Professional CAM (CSWP-CAM) exam shows that you have demonstrated your ability to use SOLIDWORKS CAM functionality and tools.

            CSWP - Simulation

            The Certified SOLIDWORKS Professional - Simulation (CSWP-Simulation) exam tests your understanding of SOLIDWORKS Simulation tools and simulation in general.

            CSWP - MBD

            The completion of the Certified SOLIDWORKS Professional Model-Based Design (CSWP-MBD) exam shows that you have successfully demonstrated your ability to use SOLIDWORKS MBD functionality and tools.

            CSWPA - Drawing Tools

            The completion of the Certified SOLIDWORKS Professional Advanced Drawing Tools (CSWPA-DT) exam proves that you have successfully demonstrated your ability to use the tools found in the SOLIDWORKS Drawing environment.

            CSWPA - Mold Making

            The completion of the Certified SOLIDWORKS Professional Mold Making (CSWPA-MM) exam shows that you have successfully demonstrated your ability to use SOLIDWORKS Mold Tools functionality with Mold Making Industry knowledge.

            CSWPA - Sheet Metal

            The completion of the Certified SOLIDWORKS Professional Advanced Sheet Metal (CSWPA-SM) exam shows that you have successfully demonstrated your ability to use SOLIDWORKS Sheet Metal tools.

            CSWPA - Surfacing

            The completion of the Certified SOLIDWORKS Professional Advanced Surfacing (CSWPA-SU) exam shows that you have successfully demonstrated your ability to use SOLIDWORKS Advanced Surfacing tools.

            CSWPA - Weldments

            The completion of the Certified SOLIDWORKS Professional Advanced Weldments (CSWPA-WD) exam proves that you have successfully demonstrated your ability to use the SOLIDWORKS tools for Weldments.

            3DEXPERIENCE - Collaborative Business Innovator

            The completion of the 3DEXPERIENCE - Collaborative Business Innovator exam shows that you have successfully demonstrated your basic knowledge of the 3DEXPERIENCE Platform.

            3DEXPERIENCE – Collaborative Industry Innovator

            The completion of the 3DEXPERIENCE – Collaborative Industry Innovator exam shows that you have successfully demonstrated your understanding of data management tools available on the 3DEXPERIENCE Platform

            3DEXPERIENCE – 3D Creator

            The completion of the 3DEXPERIENCE – 3D Creator exam shows that you have successfully demonstrated your basic knowledge of the browser-based 3D Design Role.

            3DEXPERIENCE – 3D Sculptor

            The completion of the 3DEXPERIENCE – 3DSculptor exam shows that you have successfully demonstrated your basic knowledge of the browser-based 3D Sculptor role.

            ADDITIONAL TEACHER/INSTRUCTOR CERTIFICATION

            Accredited Educator Certification

            Educators play a vital role in developing the next generation of engineering and design innovators. The SOLIDWORKS Accredited Educator certification provides educators the professional development credential to demonstrate technical proficiency and skill in the classroom.

            TECE Exam

            Technology Educator Competency Exam (TECE) is intended for educators that teach using SOLIDWORKS software in a classroom setting. The TECE demonstrates technical proficiency in classroom instruction for 3D CAD, simulation, and sustainable design.

            SOLIDWORKS Certification

            July 18, 2025 0 comments

            Mold Design

            Cimatron Mold Design

            Cimatron Mold is a single, integrated CAD/CAM software solution dedicated to mold making—from quoting, to design, to manufacturing. Deliver high-quality molds of any complexity and size in record time.

            GET QUOTE
            FREE DEMO

            Data Import

            Import your customer data and start working within seconds:

            • Start working as soon as you get your customer's part data. Heal and stitch data or work with non-stitched models and poor-quality imported data.
            • Quickly and reliably import your customer’s part data with automatic data validation and highly-accurate conversion from all standard formats including DXF, IGES, STEP, VDA, Parasolid (including binary), SAT (ACIS), STL, and SAB.
            • Take advantage of native read/write options for popular CAD systems including SOLIDWORKS®, AutoCAD®, Autodesk® Inventor®, CATIA®, PTC® Creo®, Siemens® NX™, Siemens Solid Edge®, and Autodesk® .
            • Import relevant product manufacturing information (PMI) from several proprietary formats.

            Quoting

            Win more business with quick and accurate quoting:

            • Spot undercuts—immediately locating lifters, sliders, and areas that require mending—using QuickSplit.
            • Obtain a quick and accurate estimate of the mold base cost with preliminary designs that include the placement of primary mechanisms such as sliders and runners.
            • Clearly visualize and analyze engineering changes for accurate and efficient cost estimates.
            • Produce accurate cost estimates based on a mold base layout with the MoldQuote Generator using the information you define to calculate a price for quoting automatically.
            • Print ready-to-send, professional-looking quotes that include embedded screenshots of preliminary designs.

            Parting

            Use QuickSplit, the industry’s fastest and most accurate parting and cavity design tool:

            • Start mold design immediately on any model, regardless of the part quality.
            • Ensure flawless parting with dedicated analysis tools to identify undercuts, check geometry, and verify parting surfaces.
            • Define multiple opening directions—automatically assign faces to the correct directions, supporting any number of sliders and lifters.
            • Quickly generate geometry for cores, cavities, lifters, sliders, and other active components for even the most complex molds.
            • Apply engineering changes to parting methodically at any point in the project.
            • Quickly perform mending and surfacing work using powerful hybrid solid/surface modeling capabilities tailored specifically to the tooling industry.
            • Shorten delivery times by using applicative tools to send components to NC, milling, and wire EDM on the first day of design.

            Mold Base Design

            Load an entire mold base plate set in just minutes using standard and user-defined catalog parts:

            • Easily load a standard mold base from commercial catalogs.
            • Work efficiently with non-standard mold bases using a dynamic mold base template that includes all components (plates, sliders, etc.).
            • Instantly modify component dimensions and replace parts in the mold base at any point in the mold design process.

            Mold Base Design

            Use QuickSplit, the industry’s fastest and most accurate parting and cavity design tool:

            • Start mold design immediately on any model, regardless of the part quality.
            • Ensure flawless parting with dedicated analysis tools to identify undercuts, check geometry, and verify parting surfaces.
            • Define multiple opening directions—automatically assign faces to the correct directions, supporting any number of sliders and lifters.
            • Quickly generate geometry for cores, cavities, lifters, sliders, and other active components for even the most complex molds.
            • Apply engineering changes to parting methodically at any point in the project.
            • Quickly perform mending and surfacing work using powerful hybrid solid/surface modeling capabilities tailored specifically to the tooling industry.
            • Shorten delivery times by using applicative tools to send components to NC, milling, and wire EDM on the first day of design.

            Core, Cavity, and Sliders

            Leverage automation to complete design of the mold’s main components rapidly:

            • Quickly and easily design the core, cavity, and sliders.
            • Easily implement engineering changes to mold components by maintaining associativity with initial parting work throughout the process.

            Catalog Parts

            Work with a large selection of commercial catalogs:

            • Browse through up-to-date catalog libraries to find the right part with the right dimensions.
            • Automatically adapt the catalog part or sub-assembly to the main assembly’s dimensions or to design details such as punch hole dimensions.
            • Integrate catalog parts into assemblies by automatically creating pockets in every plate the part goes through and threading the pocket where necessary.
            • Associate catalog parts with their drilling procedures to streamline NC programming.
            • Create your own personalized catalogs.
            • Access additional catalog parts using the Cadenas portal.

            Lifters Design

            Use a dedicated, applicative tool for lifters to speed the design process:

            • Place lifters from commercial or user-defined catalogs in one operation.
            • Cut even the most complex lifters automatically while previewing the faces taken into consideration in the operation to ensure an optimal result.
            • Create cavity and core pockets to enable wire EDM and milling to begin on the first day of design.

            Inserts Design

            Use a dedicated, applicative tool for inserts to speed your design process:

            • Use powerful tools to design inserts automatically, even before the plate has been cut, which allows machining to begin at an early stage.
            • Easily create wedges by applying custom shapes or manually defining their placement.
            • Cut cavity and core pockets to enable wire EDM and drilling/milling to begin on the first day of design.

            Ejection Systems

            Use dedicated, applicative tools for the ejection systems to boost your design process:

            • Add hundreds of ejectors from commercial or user-defined catalogs in a single step; the system will find the right spot, analyze the plates they go through, and take care of the trimming automatically.
            • Create pockets that are tight around the upper end of the ejector and loose along the body.
            • Associate ejectors with their drilling procedures to streamline NC programming.

            Cooling Systems Design

            Use applicative tool for cooling channels design to boost your design process:

            • Simplify the creation of complex cooling systems and all required cooling items (channels, plugs, connectors, baffles, nipples, etc.) with dedicated design tools.
            • Detect any interference and receive alerts if cooling channels are positioned too close to other key components.
            • Ensure mold and part quality by simulating the plastic filling and cooling of the mold.
            • Associate cooling channels with their drilling and gun drilling procedures to streamline NC programming.

            Conformal Cooling Design

            Use applicative tools to design conformal cooling channels and dramatically reduce the injection cycle time by using additive manufacturing technologies.

            Design

            • Use the dedicated toolset in Cimatron for fast conformal cooling design.
            • Design cooling channels of any complexity using hybrid design tools that consist of mesh, surfaces, solid, and wireframes.
            • Apply local technological offsets for post-printing (subtractive) operations.
            • Validate cooling efficiency, reduction of cooling time, and part warpage as well as filling analysis with FEA tools.

            Post-printing operations

            • Design and manufacture fixtures to mount printed inserts, considering the local technological offsets.
            • Finish the part holes and high-accuracy surfaces by using the Cimatron 2.5- to 5-axis milling and drilling capabilities.
            • Complete the work on tiny, accurate details by using the Cimatron electrode (EDM) application.

            Runners Design

            Use a dedicated, applicative tool to design the runners quickly and easily:

            • Sketch runners in 2D to automatically convert them into 3D runners with the easy addition of sprue bushing.
            • Design non-planar runners in 3D with a mechanism that helps avoid undercuts.

            Motion Analysis and Collision Detection

            Use applicative tool for cooling channels design to boost your design process:

            • Simplify the creation of complex cooling systems and all required cooling items (channels, plugs, connectors, baffles, nipples, etc.) with dedicated design tools.
            • Detect any interference and receive alerts if cooling channels are positioned too close to other key components.
            • Ensure mold and part quality by simulating the plastic filling and cooling of the mold.
            • Associate cooling channels with their drilling and gun drilling procedures to streamline NC programming.

            ECO Management

            Effectively analyze, implement, verify, track, and manage engineering change orders (ECOs):

            • Easily identify the geometry changed by the customer and the impact on mold components.
            • Automatically replace existing geometry with the ECO geometry.
            • Perform verification checks to ensure that all necessary changes have been implemented correctly.
            • Track ECOs and document changes for reporting, costings, and customer communication.

            Drawings

            Create and reuse drawing templates incorporating customer specifications:

            • Use powerful drafting options for mold drawings including the ability to create sections on open objects and broken views.
            • Easily add a bill of material and table of holes to your drawings.
            • Save time with automated placement of center lines, coordinate labels, and other drawing elements.
            • Generate drawings with all the information needed to order components, shop floor operators, quality assurance, and customer documentation.
            • Define drafting views on-the-fly during the modeling process, then quickly convert them into drawings.
            • Create and reuse templates incorporating customer standard drawing specifications.
            • Reduce drawing file size by creating links with the original data.

            Fast, Efficient Programming

            Effectively analyze, implement, verify, track, and manage engineering change orders (ECOs):

            • Enjoy background toolpath calculations and parallel execution of procedures for better hardware use and significant time savings.
            • Preview procedure results and parameters before they are calculated with a highly-accurate visualization of the remaining stock compared with the part.
            • Benefit from confident machining with a highly-accurate embedded material removal simulator, gouge and collision detection, and color-coded deviation map.
            • Benefit from centralized control over NC data and cutter support for multiple materials.
            • Reuse templates or sequences in the same project or in a totally different project. Templates and sequences can also help you standardize machining in your tool shop.

            Built-In CAD Functionality

            • Take advantage of a full hybrid system that enables you to combine wireframe, surfaces, local open solid, and solid functions as part of the NC environment.
            • Optimize machining by adding surfaces and contours, capping holes and slots, and extending surfaces, as well as applying drafts and rounds using dedicated features.

            Efficient Roughing

            • Undertake quick and effective ultra-high volume milling on 3D stock shapes with Rough VoluMill.
            • Ensure short machining times for any selected machining strategy with continuously-updated multi-axis stock.
            • Check for tool shank and holder collisions against the auto-updated stock automatically at all stages of roughing and re-roughing operations.
            • Generate a high-speed milling (HSM), all-rounded toolpath with constant tool load, trochoidal milling, advanced clean between passes, efficient rough between layers, and state-of-the-art ridge removal.

            Efficient Roughing

            • Undertake quick and effective ultra-high volume milling on 3D stock shapes with Rough VoluMill.
            • Ensure short machining times for any selected machining strategy with continuously-updated multi-axis stock.
            • Check for tool shank and holder collisions against the auto-updated stock automatically at all stages of roughing and re-roughing operations.
            • Generate a high-speed milling (HSM), all-rounded toolpath with constant tool load, trochoidal milling, advanced clean between passes, efficient rough between layers, and state-of-the-art ridge removal.

            Efficient Roughing

            • Undertake quick and effective ultra-high volume milling on 3D stock shapes with Rough VoluMill.
            • Ensure short machining times for any selected machining strategy with continuously-updated multi-axis stock.
            • Check for tool shank and holder collisions against the auto-updated stock automatically at all stages of roughing and re-roughing operations.
            • Generate a high-speed milling (HSM), all-rounded toolpath with constant tool load, trochoidal milling, advanced clean between passes, efficient rough between layers, and state-of-the-art ridge removal.

            High-Quality Finishing

              • Choose from a rich set of 3- to 5-axis-optimized machining strategies including:
                • Adaptive Z layers
                • True spiral motions
                • All rounded motions
                • Flow-line machining
                • Cleanup (rest machining) and pencil
                • Slope controlled finishing
                • Optimized CBP (clean between passes)
                • Unique ridges handling by zero overlap trochoidal
                • Prevent waterfall
                • Air extensions
                • Uniform approach and retract
              • Automatically adapt machining strategies to achieve a high, polish-free surface quality using built-in analysis of local slopes.
              • Benefit from highly-efficient machining with any cutter combination in cleanup.

            Full 5-Axis Capabilities for Mold Making

            • Reduce the need for electrodes with direct milling of narrow slots and tiny corner radiuses.
            • Use a single setup for multi-side operations.
            • Choose from a rich selection of machining strategies and support a complete range of cutters including tapered cutters, lollipop tools, and slot mill cutters.
            • Support positioning and continuous milling, providing full control over the tilt and lead angles as well as gouge and collision check of the tool shank and holder against the part.
            • Generate touch-of-a-button 5-axis tilting toolpaths, especially suitable for rapid machining of parts with deep cavities, narrow ribs, and tiny corner radiuses, using shorter and more rigid tools for best surface quality and reduced machine time.
            • Verify all toolpaths and eliminate unnecessary tryouts with advanced post-processor-based simulation capabilities including material removal, remaining stock, and complete machine kinematics.

            Plate Machining and Drilling

            • Achieve efficient and accurate machining of plates with powerful pocket or profile milling options and full drilling capabilities.
            • Use flexible sequences for faster programming of hole drilling.
            • Save 90 percent of drill programming time by allowing the system to assign appropriate drilling sequences for hundreds of holes in seconds automatically.
            • Produce optimized cooling channels with gun drilling machines using automatic intersection detection and optimized drilling order.
            • Enjoy automatic transfer of hole properties assigned during the tool design phase and save time with reduced sequence management.
            • Program wire EDM machining in 2- or 4-axis wire modes, ensuring optimal CNC performance with a built-in database of EDM machines.
            • Check for gouges with holder collision check against the part, actual remaining stock, and clamps.

            Advanced Micro Milling for Miniature, High-Precision Milling

            • Cimatron is a pioneer in the field of micro milling, offering dedicated micro-machining strategies to manufacture molds for very small, high precision parts cost-effectively.
              • Generate superb surface quality with tolerances as tight as 0.0001mm using cutting tools with diameters as small as 0.1 mm.
              • Use the Cimatron micro-milling capabilities to support cutting-edge direct milling.

            Simulation and Post-Processor Support

            • View the cutting process and its results prior to machining with a color-coded display to help analyze the remaining material around the part.
            • Simulate the real machine kinematics and toolpath motion checking tool shanks and holders against the part with advanced simulation generated with the G-code. The ability to predict machine behavior enables you to correct and eliminate errors ahead of time.
            • Choose from a rich library of post processors for practically all 3-axis and 5-axis machines as well as all leading controllers.
            • Easily customize a state-of-the-art post-processor generator to any specific needs.

            Simulation and Post-Processor Support

            • View the cutting process and its results prior to machining with a color-coded display to help analyze the remaining material around the part.
            • Simulate the real machine kinematics and toolpath motion checking tool shanks and holders against the part with advanced simulation generated with the G-code. The ability to predict machine behavior enables you to correct and eliminate errors ahead of time.
            • Choose from a rich library of post processors for practically all 3-axis and 5-axis machines as well as all leading controllers.
            • Easily customize a state-of-the-art post-processor generator to any specific needs.

            July 5, 2021 0 comments

            Customer Success Stories

            Customer Stories

            Learn how SOLIDWORKS software has helped companies in many diverse industries

            to improve their products, increase their productivity, and reduce their costs

            with our Customer Success Stories.

            ARIV Technologies Pvt.Ltd

            ARIV Technologies is Engineering Service provider experienced in Design Automation, Product Design,
            Read more...

            Bailey Hydropower Pvt Ltd.

            Wayne Burt Systems, Inc – Atlanta based US corporation having state of art manufacturing facilities in
            Read more...

            Ceeyes Metals Reclamations Pvt Ltd.

            Ceeyes Metals Reclamations Pvt Ltd established in year 1991, started Started out as a private firm with an objective to
            Read more...

            Centroid

            Centroid Creative Hubb started in the year 2005, is a fast growing and a leading Industrial design consultancy in
            Read more...

            Madura Machine Tools

            Madura Machine Tools is into Design & Manufacturers of SPM’s and Automation also specialist in metal
            Read more...

            Mechasoft

            MECHASOFT established in year 2004 as CAD/CAM Solution provider who has Die and pattern making facility and
            Read more...

            Nu-Tech Industrial Spares & Services (P) Ltd.

            Nu-Tech manufacture and supply windmill components to established OEMs and other end users
            Read more...

            Simgrosys Consulting Services Pvt Ltd

            Simgrosys is a leading engineering services provider with its operation centre in India and business offices in Americas,
            Read more...

            Spudweb Technologies India Pvt. Ltd

            Spudweb is a 16 years old company which is into IT enabled infrastructure products and started a technology division in 2009
            Read more...

            Rambal Ltd.

            Rambal Limited has been in the business of precision auto components since 1957.
            Read more...

            Astrox Aerospace Private Limited

            At AstroX Aerospace, we’re not just another startup.
            Read more...

            SRI BALAJI PLASTICS

            With 20+ years in the industry, we have been at the forefront driven by a successful
            Read more...

            Flow Control Commune

            Understands our unique requirements and offers extensive support and solutions
            Read more...

            K-lite Industries

            K-lite guided by a culture of continuous improvement and customer focus
            Read more...

            LLM Appliances Private Limited

            Promoted by a family of traditional entrepreneurs, LLM Appliances Private Limited (formerly LLM Appliances Limited (LLMAPL)
            Read more...

            SKYX AEROSPACE PRIVATE LIMITED

            At SXYX AAEROSPACE, we pioneer in developing Drones for all Business use cases in accordance with the Govt.
            Read more...

            Susin Technologies Private Limited

            Technocrat with 18 years of experiences in the Foundry castings, Machined parts and products developments.
            Read more...

            AUROLAB

            With a single minded focus on eliminating needless blindness
            Read more...

            HYDROPRESS INDUSTRIES

            Hydro press industries is one of the leading manufacturers and exporters
            Read more...

            KONFORM EQUIPMENTS PVT LTD

            Automate the possible activities of farmers , Food shops , Juice shops, Tea shops and Agro product process activities, without violating safety
            Read more...

            RDX DIGITAL TECHNOLOGIES

            With a prime focus on delivering unparalleled digital printing solutions, our services are meticulously designed
            Read more...

            Customer Stories

            SUBA PLASTICS PVT. LTD

            Manufacturing Injection molded Engineering components ranging from 0.04grams to 2600 grams
            Read more...

            Back to Top
            Product has been added to your cart
