3DEXPERIENCE 3DSpace App

3DSpace is a core application of the 3DEXPERIENCE platform designed for project management and collaboration. It serves as a centralized repository for project data, enabling teams to access, manage, and share information seamlessly.

Features:

1. Centralized Data Management

3DSpace allows users to store and organize all project-related information in one location.

2. Intuitive User Interface

With a user-friendly interface, 3DSpace simplifies navigation and data retrieval. Users can easily search for documents, models, and other project files.

3. Version Control

Allowing teams to track changes, manage revisions, and ensure that everyone is working with the most up-to-date information. This capability is crucial for maintaining data integrity throughout the project lifecycle.

4. Collaborative Workspaces

3DSpace provides collaborative workspaces where team members can share ideas, feedback, and project updates in real-time. This helps teams stay aligned on project goals.

Getting Started with 3DSpace

Accessing the App

Step 1: Create a Collaborative Space



To get started, you need to create a Collaborative Space in 3DSpace. This is where all your project files and data will be stored.

  • Go to the 3DEXPERIENCE dashboard and select the 3DSpace app from the menu.
  • Click on “New Collaborative Space” to set up a new space for your project
  • Name your space based on your project (e.g., "Project X Design Files").
  • Define roles and permissions: Decide who will have access to this space and what actions they can take (view, edit, etc.).

Step 2: Add Team Members

Now that you have your Collaborative Space set up, it’s time to bring your team in.

  • Within the space, click on “Members” or “Add Participants”.
  • Search for your team members by name or email and invite them to the space.
  • Assign roles to each team member (e.g., viewer, editor, project manager). This controls what they can do inside the space.

Set up folders for different tasks or project phases to keep everything easy to find.

  •  Add tags or keywords to files to quickly find them during searches.
  • 3DEXPERIENCE platform for viewing models, sharing ideas, or tracking tasks.

Benefits:

  • Enhanced Collaboration With 3DSpace, teams can work together more effectively,
  • Improved Efficiency By centralizing project data and streamlining workflows
  • Better Decision-Making Access to real-time data and insights enables teams to make informed decisions quickly.
  • 3DSpace supports projects of varying sizes and complexities, providing scalability for diverse project needs.

Conclusion:

  • The 3DSpace app within the 3DEXPERIENCE platform is a powerful tool for enhancing collaboration and project management.
  • By centralizing data, promoting teamwork, and integrating with other applications, 3DSpace helps teams work more efficiently and effectively.

Click Here to Get SOLIDWORKS License

Click Here to Get SOLIDWORKS Trainings

Click Here to Explore Additive Manufacturing
November 4, 2024 0 comments

Drafter (WDR-OC) 3DEXPERIENCE

Drafter (WDR-OC) enables rapid conversion of 3D models into accurate 2D drawings, significantly enhancing the product development cycle. With real-time updates, modifications to the 3D model are instantly reflected in the 2D drawings, minimizing errors. Users can easily annotate and dimension their drawings, facilitating clear communication among team members. Integrated with the 3DEXPERIENCE platform.

Drafter allows for easy sharing and access to drawings from any device, enhancing collaboration. This streamlined approach reduces the time and cost associated with the design-to-manufacturing process, optimizing workflows and allowing teams to focus on creativity and innovation. Ultimately, Drafter is an invaluable asset for design and engineering teams.

Overview

Connected to the 3DEXPERIENCE® platform, Drafter is a Windows-based application that rapidly derives 2D drawings from your 3D models. One of its standout features is the ability to update drawings instantly whenever modifications are made to the 3D design. With Drafter’s comprehensive, production-quality drawing and detailing capabilities, designers and engineers can easily annotate and add dimensions to their drawings. Plus, with data saved to the cloud, sharing drawings in real time has never been easier.

Key Features

Fully Associative 2D Drawings:

Drafter ensures that every 2D drawing is dynamically linked to its corresponding 3D model. This powerful integration means that any adjustments made to the 3D design—whether minor tweaks or significant overhauls—are automatically reflected in the associated 2D drawings. Your documentation is always accurate, reducing the risk of errors and discrepancies.

Efficient Design Communication:

Clear communication is essential in manufacturing. Drafter provides intuitive tools to apply dimensions, annotations, and cross-sections to your drawings. This functionality helps convey complex manufacturing requirements in a straightforward manner, facilitating better understanding among team members and stakeholders.

Accelerated Product Development:

In a competitive market, speed is essential. Drafter significantly reduces the time required to transition from design to manufacturing. By automating the drawing update process, your team can focus more on innovation and less on manual documentation tasks, giving your business a competitive edge.

Capabilities of Drafter

  • Quickly generate detailed drawings from your 3D parts and assemblies with ease.
  • Effortlessly apply dimensions, annotations, and cross-sections to enhance your drawings.
  • Your 2D drawings update instantly whenever you modify your 3D model, thanks to powerful integration.

Benefits of Using Drafter

Real-Time Updates: Enjoy the confidence that comes with knowing your 2D drawings are always accurate. The automatic update feature eliminates the tedious task of manual revisions.

Enhanced Productivity: By streamlining the drawing generation process, Drafter allows your team to focus on creative problem-solving and refining product designs.

Cost Efficiency: Less time spent on documentation directly translates to lower costs, helping you bring products to market faster.

Conclusion

Drafter (WDR-OC) is an essential tool for designers and engineers, integrating powerful drawing capabilities with the 3DEXPERIENCE platform to transform product development. It enhances accuracy, improves communication, and streamlines workflows while reducing costs and boosting productivity. Using Drafter can elevate your design processes and help you meet project goals. In today’s fast-paced environment, having the right tools is crucial, so start using Drafter today and see how it can improve your product development cycle.

Click Here to Get SOLIDWORKS License

Click Here to Get SOLIDWORKS Trainings

Click Here to Explore Additive Manufacturing

Drafter WDR-OC 3DEXPERIENCE
April 5, 2024 0 comments

Collaborative Lifecycle Management :How to access the Collaborative Lifecycle role in order to build revision management

Imagine a world where managing revisions for your 3D projects is a breeze. No more confusion over version numbers or lost updates. This is the power of Collaborative Lifecycle Management (CLM) within the Open 3D Experience Platform. CLM empowers you to track changes, create branches, and effortlessly merge revisions, all while fostering seamless collaboration throughout your design process.

Harnessing the Power of Collaborative Lifecycle Management:

The Open 3D Experience Platform offers a robust set of tools accessible through Google Chrome. By leveraging your 3D Passport credentials, you can unlock the full potential of CLM. Here's a step-by-step guide to get you started:

1. Access the Collaborative Industry Innovator Role:

Upon logging in, navigate to the Compass icon. This will grant you access to the Collaborative Industry Innovator role, where you'll find the CLM app.

2. Launch the Collaborative Lifecycle App:

Double-clicking the CLM app icon will launch it within the platform.

3. Open Your Model and Initiate Revisions:

Select your desired model within the 3D space and open it within the CLM interface. This will initiate a new conversation for the updated revision.

4. Provide Revision Details:

This is where you can clearly document any changes made to the model. A detailed revision history is key for maintaining transparency and efficient collaboration.

5. Finalize the Revision:

Once you've documented the revision details, simply click "Revise" to commit the changes and update the file revision.

Beyond the Basics: Unlocking the Full Potential of CLM

While the above steps provide a foundational understanding of CLM, its capabilities extend far beyond basic revision control. This powerful tool allows you to:

  • Create and Manage Branches: Facilitate parallel development by creating separate branches for different design iterations. This enables exploration of alternative concepts without jeopardizing the core model.
  • Effortless Merging: Seamlessly integrate changes from various branches back into the main model, ensuring all team members are working with the most up-to-date version.
  • Enhanced Collaboration: CLM fosters a collaborative environment by providing a clear historical record of changes, revisions, and contributors. This promotes transparency and streamlines communication within your design team.

Conclusion

By incorporating Collaborative Lifecycle Management into your workflow, you can revolutionize the way you manage revisions and propel your 3D design projects to new heights. With its intuitive interface and comprehensive features, CLM empowers you to maintain control, streamline collaboration, and unlock the full potential of your design vision.
March 29, 2024 0 comments

Creation of PLC in library of SOLIDWORKS ELECTRICAL

Creating a PLC in SOLIDWORKS ELECTRICAL SCHEMATICS and customizing the PLC according to our requirement.

Include this connector in your schematic diagrams to connect symbols like relays, contactors, sensors, and signals.

                     The creation of a PLC involves following a few steps. Once created, the same PLC specifications can be used for connections within SOLIDWORKS Electrical schematics.

STEP 1

  • To create a PLC first it must store in the library. The library permanently stores created connectors until you remove them manually
  • To create a PLC as shown in the below image first have to goto Library -> Manufacturer part management.

STEP 2

Manufacturer part management

  • Once the above points done.
  • Manufacturer part management will consist of more number classifications(folders). This section actively separates and organizes all components into different folders.
  • Selecting the PLC folder filters the manufacturer part management tab on the right side, displaying only PLC-related manufacturers already present in the library.
  • Selecting the "ADD MANUFACTURER PART" option allows you to create a new PLC. The system will provide a separate tab to enter details specific to the PLC.

STEP 3

New PLC details adding In Solidworks Electrical

  • Once the above points done.
  •  The system will open a Manufacturer Part Properties tab.
  • In this section three options will be present PROPERTIES, USER DATA, CIRCUIT, TERMINALS
  • The Properties tab requires you to fill in essential details like reference and manufacturer. Scrolling down reveals additional optional specifications such as height, weight, frequencies, and supplier name.

STEP 4

Specifications of Circuit, Terminal

  • With continuation of above points
  • The third option, Circuit Terminals, lets you add circuit types.
  •  At the top circuit, terminal option will be present near to the properties tab.
  • This tab allows you to add circuits using the ADD option
  • The ADD MULTIPLE option, illustrated in the image below, allows you to efficiently add multiple circuits at once

STEP 5

Add Multiple Circuits In Solidworks Electrical

  • The image below demonstrates how to quickly and easily add multiple circuits.
  • All circuits type are present in the scroll down. Select circuits based on your specific requirements.

Summary

  • With these above-mentioned points we can able to create a PLC in a solidworks electrical.
  • By following these steps, you will create a new connector that gets added to the SOLIDWORKS Electrical library for future use.
March 21, 2024 0 comments

3DEXPERIENCE Exchange – Import and Export Package

Let us see how we can Import and Export Package with 3DEXPERIENCE Exchange.

Collaborating together with users outside of your company has always been better! Assembly files can be easily bundled into a single package file by using the Export as a Package capability. You can share this file with third-party suppliers so you can track and get back their modifications. Even the files that are editable within the package can be restricted.

Similar to SOLIDWORKS Pack and Go, but with more ease of use as well as integration with 3DEXPERIENCE Platform products, is this capability.

How to Export as Package:

1. In 3DEXPERINCE SOLIDWORKS, open the assembly file you would like to share with External Stack Holder.

2. To save, pick Tools from the 3DEXPERIENCE tab on the right, choose Export, and then select Export as Package.

3. On the launch of the export window, you have the option to mark assemblies and components as read-only or editable for whoever you are sharing data with

4. Following that, providing the package a name and choose Export. The 3DEXPERIENCE Platform permits you to save the package file (.sldpkg) locally or to 3DDrive.

How to Import as Package with 3DEXPERIENCE Exchange for SOLIDWORKS:

1. Initially ensure certain SOLIDWORKS' "3DEXPERIENCE Exchange" Add-in is activated.

2. Select the 3DEXPERIENCE Exchange tab on task plane, then pick Import Package.

3. To open the ".sldpkg" file that you received, click the "Open" icon in the "Import Package" Window. A working folder will be created when importing this package, and its default path will be taken automatically.

4. The window on the right will display the files that are read-only or unchanged when the package has been imported.

5. The window on the right will display the files that are read-only or unchanged when the package has been imported.

Export Package:

Once you've decided to send the updated package back to the the sender, select Package, Export. The revised ".sldpkg" file can be saved from here on and forwarded to the 3DEXPERIENCE user you are collaborating with.
March 8, 2024 0 comments

Utilizing 3DEXPERIENCE SOLIDWORKS – Revisions Update

Managing Reference Component Revisions in 3DEXPERIENCE SOLIDWORKS

This blog post explains how to revise components within the SOLIDWORKS My Session Task Pane of the 3DEXPERIENCE platform. It covers the different approaches available and clarifies how to handle situations where reference components appear outdated.

This lesson demonstrates the many approaches to revising these components.

Challenges with Updating Downloaded Assemblies

When you download an assembly from the 3DEXPERIENCE platform and then update its reference components, those components might still show up in the Task Pane with the previous revision. This lesson will guide you through various methods to revise these components effectively.

Updating Individual Components

There are two main ways to update individual components:

  1. Replace by Revision: Right-click a component in the Task Pane that has a newer revision available. Select "Replace by Revision" from the menu. This brings up a dialog box showcasing all compatible revisions for that component.
    • Latest Revision: This option replaces the component with its most recent revision.
    • Important Note: This functionality only works for components that have child references (components with derived parts or contextual connections).

2. Update Revisions in Top-Level Assembly: Selecting "Update Revision" on a top-level assembly offers a more streamlined approach. This action triggers a dialog box displaying the entire assembly structure. Next to each component, a drop-down list appears, allowing you to efficiently select the latest revision for multiple components simultaneously. This eliminates the need to update revisions one by one.

Important Considerations During Updates:

Warning Message: When replacing a file with a different revision while it still shows as updated in the Task Pane, a warning message will pop up. This message informs you that any local changes made to the file will be overwritten. It's recommended to back up your data beforehand if necessary.

Latest Revisions Update:

Selecting the "Update Revision" option on a top-level assembly streamlines the process. Consequently, a dialog box will appear, conveniently displaying the entire assembly structure. Furthermore, a drop-down list will be available next to each component, allowing you to efficiently link the most recent revisions of multiple components simultaneously. This eliminates the need to update each revision individually, as previously mentioned.

  1. Replacing a component with the most recent revision available.
  2. Replacing a component with the most recent stable revision takes it back to its most recent frozen or released lifecycle stage.
  3. Replace with Most Recent Released Revision: Replace a component exclusively with the most recent revision to be made public.

Note: The option Replace by Latest Revision will be the only one available if there are only unreleased versions.

Updating All Components to Latest Revision

If you want to update all components within an assembly to their latest revisions at once, you don't need to use the drop-down menu for each component individually.

Simply select "Replace All" from the top right corner of the dialog box that appears when you choose "Update Revision" on the top-level assembly. This will instantly update all components to their most recent versions.

Additional Resources

You can find all the settings mentioned above within the Lifecycle tab located at the bottom of the My Session Task Pane.

This concludes the lesson on updating revisions in SOLIDWORKS My Session Task Pane. If you'd like to learn more about the 3DEXPERIENCE platform and SOLIDWORKS, explore the articles provided below.
February 20, 2024 0 comments

Bookmark Editor On The 3DEXPERIENCE Platform

In 3DEXPERIENCE platform, the Bookmark Editor empowers you to streamline cloud data organization and management. Imagine creating a personalized filing system based on projects, departments, products, or any other criteria that suits your workflow. This blog post delves into four key tips to unlock the full potential of the Bookmark Editor and transform your data management experience.

  1. Customise the columns on your bookmark editor.
  2. Enable Product Expansion.
  3. Remove File vs Delete File.
  4. Index and Authoring in Active Mode.

1. Customize the columns on your bookmark editor:

The Bookmark Editor displays a wealth of information about each file within its top row columns. These columns are instrumental in organizing and managing your data effectively. Tailor these columns to your specific needs by dragging and dropping them for rearrangement and selecting which ones to display.

Pro Tip: Right-click any column header and choose "Tree List View Options" to manage column visibility. This menu allows you to select the specific columns you want to display (Step 2). For even more granular control, click the settings gear in the upper right corner (Step 3) and navigate to "More Attributes" followed by "Select Attributes" (Step 4 & Step 5) to add even more columns.

2. Leverage Product Expansion for Effortless Navigation

Subassemblies and subcomponents become a breeze to navigate with product expansion enabled. Simply access the drop-down menu in the upper right corner of your Bookmark Editor Widget (Step 1) and select "Preferences" (Step 2)

. Next, activate the checkbox labelled "Enable product expansion" (Step 3). This will add a plus sign (+) to your files, allowing you to expand them and effortlessly view sub-components.

3. Understanding Remove vs. Delete: Keep Your Data Organized

The Bookmark Editor of 3DEXPERIENCE Platform offers two options for file management: Remove and Delete. It's crucial to understand the distinction between these two functions.

  • Remove: This action removes the selected file from the current Bookmark only. The file itself remains within the Collaborative Space where it was originally saved and can still be accessed through other Bookmarks.
  • Delete: This permanent action removes the selected file from your entire Platform. Use this option with caution, as deleted files cannot be recovered.

4. Switch Between Indexing and Authoring Modes for Real-time Updates

The Bookmark Editor offers two viewing modes: Indexing and Authoring. Indexing mode, the default setting, displays the latest items available from the server's database. However, there might be a slight delay in reflecting recent modifications or uploads due to the indexing process.

To view the most up-to-date changes, switch to Authoring mode. This mode allows you to see any files still being indexed. Keep in mind that the window will automatically revert to Indexing mode after a minute in Authoring mode, unless you adjust this behavior in the Preferences.

Unleash the Power of the Bookmark Editor

By incorporating these essential tips, you can transform the Bookmark Editor into a powerful tool for managing your cloud data within the 3DEXPERIENCE platform. From customized column views to seamless navigation and control over file management, the Bookmark Editor empowers you to organize and access your data with greater efficiency.
